Установкa Thermo King V-520 SPECTRUM схема EVAPORATOR COMPONENTS ES300 – 233E4
Обновление от: 8/25/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 67-2423 | COIL - evaporator | 1 | |
| 2 | 33-3135 | GROMMET (35 mm dia) | 7 | |
| 3 | 61-1126 | FILTER - expansion valve | 1 | |
| 4 | 66-9314 | BODY - expansion valve | 1 | |
|
66-9314 OEM | ТРВ, V/VM-Series MAX (R404A) | 31 890 ₽ |
|
| 203-534 | TAPE - insulating | A/R | ||
| 5 | 41-3136 | SWITCH - defrost (front evaporator, 720163) | 1 | |
| 55-9900 | SCREW - switch | 2 | ||
| 6 | 41-5784 | SENSOR - temperature (w/ connector) | 1 | |
| 42-3067 OEM | Датчик температуры, V-Series | 12 360 ₽ |
|
|
| 10-42-3067 | Датчик температуры, V-Series | 9 420 ₽ |
|
|
| 55-9825 | CLAMP - sensor | 1 | ||
| 55-9452 | SCREW - clamp | 1 | ||
| 55-7697 | FLATWASHER | 2 | ||
| 55-7861 | LOCKWASHER | 1 | ||
| 55-7698 | NUT | 1 | ||
| 7 | 78-1181 | FAN - evaporator (225 mm, 12V) | 2 | |
| 78-1372 | FAN - evaporator (225 mm, 24V) | 2 | ||
| 8 | 92-596 | SCREEN - fan | 2 | |
| 55-7366 | SCREW - fan & screen | 8 | ||
| 55-9826 | FLATWASHER | 16 | ||
| 55-7404 | LOCKWASHER | 8 | ||
| 55-7367 | NUT | 8 | ||
| 9 | 98-8705 | COVER - evaporator | 1 | |
| 55-7366 | SCREW - cover | 7 | ||
| 55-7404 | LOCKWASHER | 7 | ||
| 55-9826 | FLATWASHER | 7 | ||
| 10 | 42-230 | HARNESS - defrost drain hose (12V) | 2 | |
| 42-395 | HARNESS - defrost drain hose (24V) | 2 | ||
| 11 | 61-4939 | TUBE ASSEMBLY - defrost | 1 | |
| 12 | 61-4940 | TUBE ASSEMBLY - liquid | 1 | |
| 13 | 66-7878 | SOLENOID - defrost & liquid | 1 | |
| 14 | 41-5789 | COIL - solenoid (12VDC) | 1 | |
| 41-5791 | COIL - solenoid (24VDC) | 1 | ||
|
10-41-5791 | Катушка соленоида 24V, V-Series | 4 200 ₽ |
|
| 15 | 92-8131 | BRACKET - valve | 2 | |
| 55-7340 | SCREW - bracket | 2 | ||
| 55-7089 | FLATWASHER | 4 | ||
| 55-7034 | NUT | 2 | ||
| 16 | 33-1015 | O-RING - liquid & defrost | 4 | |
| 33-1015 OEM | О-ринг фильтра-осушителя, 3/8" | 240 ₽ |
|
