Установкa Thermo King V-500 MAX TC 10, 20, 30, 50 схема V-500 MAX TC 10/20/30/50 REFERENCE SHEET – 7U71
Обновление от: 1/3/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 920032 | V-500 MAX TC-10 | 12/04 | ||
| 920033 | V-500 MAX TC-20 | 12/04 | ||
| 720161 | Condenser - V-500 MAX TC-10 | 12/04 | ||
| 720162 | Condenser - V-500 MAX TC-20 | 12/04 | ||
| 720163 | Evaporator - ES-300 MAX TC | 12/04 | ||
| 720165 | Evaporator - ES-300 MAX TC Remote | 12/04 | ||
| 085266 | 12V V-500 MAX TC-20 | 12/04 | ||
| 085267 | 24V V-500 MAX TC-20 | 12/04 | ||
| 085268 | 12V V-500 MAX TC-10 | 12/04 | ||
| 085269 | 24V V-500 MAX TC-10 | 12/04 | ||
| 085270 | 380/3/50 V-500 TC | 12/04 | ||
| 085271 | 230/3/60 V-500 TC | 12/04 | ||
| 085272 | TC-20 Version 12V/24V | 12/04 | ||
| 085273 | TC-50 Version 12V | 12/04 | ||
| 085274 | TC-50 Version 24V | 12/04 | ||
| 085275 | TC-10 Version 12V/24V | 12/04 | ||
| 085276 | TC-30 Version 12V | 12/04 | ||
| 085277 | TC-30 Version 24V | 12/04 | ||
| 718267 | Compressor - TM16HD 12V | 12/04 | ||
| 718268 | Compressor - TM16HD 24V | 12/04 | ||
| 718741 | Accutrac 4 Temp | 12/04 | ||
| 720173 | Hose Kit - V-500 MAX TC | 12/04 | ||
| 880090 | Installation Kit - V-500 MAX TC | 12/04 | ||
| 720272 | Compressor Fittings | 12/04 | ||
| 720299 | Compressor - TM16HD | 12/04 | ||
| 720300 | Compressor - TK 312R 12V | 4/03 | ||
| 720301 | Compressor - TK 312R 24V | 4/03 | ||
| 720302 | Hoses - TK 312R Compressor | 4/03 | ||
| 720303 | Installation Kit - TK312R | 4/03 |
