Установкa Thermo King V-500 AC 10, 20 DSR схема HOSE GROUP – 219G2
Обновление от: 8/31/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 102-842 | COMPRESSOR - TM16-XD (12V) | 1 | |
|
10-TM-16 | Компрессор, TM-16, 12V 2A, R134A/R404A | 22 740 ₽ |
|
| 102-843 | COMPRESSOR - TM16-XD (24V) | 1 | ||
|
10-TM-16-24 | Компрессор, TM-16, 24V 2A, R134A/R404A | 22 740 ₽ |
|
| 2 | 51-2462 | FITTING - 90 deg (w/ charging port, #12 hose & #10 fitting) | 1 | |
| 33-672 | O-RING (9/16 id, #12) | 1 | ||
|
10-33-672 | Прокладка компрессора Regulator | 410 ₽ |
|
| 33-672 OEM | Прокладка компрессора Regulator | 80 ₽ |
|
|
| 3 | 51-2433 | FITTING (90 deg, #12) | 1 | |
| 4 | 55-9987 | FITTING (45 deg, #12) | 1 | |
| 5 | 51-2488 | FITTING (90 deg, #12) | 1 | |
| 33-1222 | O-RING (3/4 id, #12) | 3 | ||
| 6 | 55-9414 | CAGE (#12) | 4 | |
| 7 | 55-9418 | CLIP (#12) | 8 | |
| 8 | 51-2432 | FITTING (90 deg, #8) | 1 | |
| 33-2350 | O-RING (7/16 id, #8) | 1 | ||
| 9 | 51-2423 | FITTING (90 deg, #8) | 1 | |
| 33-566 | O-RING (1/2 id, #8) | 1 | ||
| 10 | 55-9412 | CAGE (#8) | 2 | |
| 11 | 55-9416 | CLIP (#8) | 4 | |
| 12 | 51-2448 | FITTING (90 deg, #10) | 2 | |
| 33-2115 | O-RING (5/8 id, #10) | 2 | ||
| 13 | 55-9413 | CAGE (#10) | 2 | |
| 14 | 55-9417 | CLIP (#10) | 4 | |
| 15 | 51-2436 | FITTING (90 deg, #6) | 5 | |
| 16 | 51-2492 | FITTING (90 deg, #6) | 1 | |
| 33-1015 | O-RING (3/8 id, #6) | 6 | ||
| 33-1015 OEM | О-ринг фильтра-осушителя, 3/8" | 240 ₽ |
|
|
| 17 | 55-9411 | CAGE (#6) | 6 | |
| 18 | 55-9415 | CLIP (#6) | 12 | |
| 19 | 67-1711 | HOSE - refrigeration (#12) | A/R | |
| 20 | 67-1710 | HOSE - refrigeration (#10) | A/R | |
| 21 | 67-1709 | HOSE - refrigeration (#8) | A/R | |
| 22 | 67-1708 | HOSE - refrigeration (#6) | A/R | |
| 23 | 55-9258 | CONNECTOR - hose | 1 | |
| 24 | 92-3469 | HOSE - drain | A/R | |
| 25 | 92-3842 | CLAMP - hose (30 mm) | 6 | |
| 92-1903 | CLAMP - hose (22 mm) | 4 | ||
| 92-3841 | CLAMP - hose (18 mm) | 3 | ||
| 51-792 | SCREW - clamp | 15 | ||
| 26 | 61-3990 | ADAPTER - suction, A/C evap | 1 | |
| 27 | 61-3991 | ADAPTER - liquid, A/C evap | 1 | |
| 28 | 92-3992 | FLANGE - A/C connectors | 1 |
