Установкa Thermo King V-300 Series DSR схема HEAT COMPONENTS (V-100 30 & 50 Mar 09 - Nov 11, V-200/300 30, Jan 09 - Nov 10) – 236H0
Обновление от: 11/23/11
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 98-8245 | COVER - MH | 1 | |
| 2 | 92-1660 | NAMEPLATE - TK (64MM) | 1 | |
| 3 | 51-2010 | SCREW - cover | 2 | |
| 55-9490 | LOCKWASHER | 2 | ||
| 55-9492 | WASHER - cosmetic | 2 | ||
| 55-9491 | CAP - cosmetic | 2 | ||
| 55-9505 | CLIP - threaded | 2 | ||
| 4 | 61-432 | FITTING - suction (#10) | 2 | |
| 33-2115 | O-RING (#10, 5/8 id) | 2 | ||
| 5 | 61-4761 | TUBE - fitting to valve | 1 | |
| 6 | 22-1073 | VALVE - pressure regulator | 1 | |
| 7 | 61-2508 | TUBE - valve to tank | 1 | |
| 8 | 67-1693 | TANK - accumulator | 1 | |
| 9 | 61-4762 | TUBE - suction (tank to fitting) | 1 | |
| 10 | 55-2688 | CLAMP - tank | 1 | |
| 11 | 92-1580 | SADDLE - tube (1/2 inch) | 1 | |
| 55-9898 | RIVET - saddle | 1 | ||
| 12 | 98-8296 | FRAME - MH | 1 | |
| 55-7172 | SCREW - frame | 4 | ||
| 55-7042 | NUT | 4 |
