Установкa Thermo King V-280 схема HARNESS- EVAPORATOR – 153B2
Обновление от: 8/17/11
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 41-3070 | HARNESS - evaporator | 1 | |
| 2 | 44-9903 | CONNECTOR - pc board (see 112D9) | 1 | |
| 3 | 44-7330 | CONNECTOR - hpco (see 115D14) | 1 | |
| 4 | 44-9631 | RECEPTACLE - door switch (see 112D9) | 1 | |
| 5 | 44-5838 | CONNECTOR - fan (see 115D14) | 1 | |
| 6 | 44-5835 | CONNECTOR - lpco (see 115D14) | 1 | |
| 7 | 41-4409 | TERMINAL - ring (red #8, 22-16 gauge) | 1 | |
| 44-2789 | TERMINAL - ring (blue 1/4, 14-16 ga) | 1 |
