Установкa Thermo King V-200 Series схема V-200 SERIES REFERENCE SHEET – 5U66
Обновление от: 2/2/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 918247 | System - V-200 10 | 1/12 | ||
| 918248 | System - V-200 20 | 7/05 | ||
| 918249 | System - V-200 10 MAX | 1/12 | ||
| 918250 | System - V-200 20 MAX | 7/05 | ||
| 718251 | Condenser - V-200 20 MAX | 7/05 | ||
| 718256 | Condenser - V-200 20 | 7/05 | ||
| 718260 | Condenser - V-200 10 MAX | 1/12 | ||
| 718275 | Condenser - V-200 10 | 1/12 | ||
| 718252 | Evaporator - V-200 MAX | 1/12 | ||
| 718258 | Evaporator - V-200 | 1/12 | ||
| 818262 | Installation Kit - V-200 10 | 1/12 | ||
| 818246 | Installation Kit - V-200 20 | 7/05 | ||
| 818247 | Installation Kit - V-200 10 MAX | 1/12 | ||
| 818240 | Installation Kit - V-200 20 MAX | 7/05 | ||
| 085108 | 12V V-200 20 MAX | 7/05 | ||
| 085119 | 12V V-200 20 | 7/05 | ||
| 085109 | 24V V-200 20 MAX | 7/05 | ||
| 085120 | 24V V-200 20 | 7/05 | ||
| 085155 | 12V V-200 10 MAX | 1/12 | ||
| 085162 | 12V V-200 10 | 1/12 | ||
| 085156 | 24V V-200 10 MAX | 1/12 | ||
| 085163 | 24V V-200 10 | 1/12 | ||
| 085110 | 380/3/50 V-200 20 MAX | 7/05 | ||
| 085111 | 230/1/50 V-200 20 MAX | 7/05 | ||
| 085112 | 230/3/60 V-200 20 MAX | 7/05 | ||
| 085113 | 230/1/60 V-200 20 MAX | 7/05 | ||
| 085114 | 115/1/60 V-200 20 MAX | 7/05 | ||
| 085121 | 380/3/50 V-200 20 | 7/05 | ||
| 085122 | 220/1/50 V-200 20 | 7/05 | ||
| 085124 | 230/3/60 V-200 20 | 7/05 | ||
| 085125 | 230/1/60 V-200 20 | 7/05 | ||
| 085126 | 115/1/60 V-200 20 | 7/05 | ||
| 700705 | Rooftop Installation Kit | 1/12 | ||
| 702823 | Compressor TM16-XD 12V PV8 119 mm | 1/12 | ||
| 702824 | Compressor TM16-XD 12VDC PV8 | 1/12 | ||
| 702825 | Compressor TM16-XD 12V 2A 135 MM | 1/12 | ||
| 702826 | Compressor TM15-XD 12V 2A 135 MM | 1/12 | ||
| 702827 | Compressor 13XD 12V 2A 135D MM | 1/12 | ||
| 702828 | Compressor 13XD 12V PV8 120 MM | 1/12 | ||
| 702829 | Compressor TM15-XD 12V PV8 120 MM | 1/12 | ||
| 702830 | Compressor TM16-XD 12VDC 1A/1B 135 MM | 1/12 | ||
| 702832 | Compressor TM15-XD 12V VG 159 MM | 1/12 | ||
| 702927 | Compressor TM16-HD DM 12VDC 2A 1 | 1/12 | ||
| 718263 | Heat Option - 12V | 7/05 | ||
| 718265 | Heat Option - 24V | 7/05 | ||
| 718269 | Compressor - TM13HD 12V | 7/05 | ||
| 718270 | Compressor - TM13HD 24V | 7/05 | ||
| 718741 | Accutrac 4 Temp | 1/12 | ||
| 718746 | Hose Kit - V-200 10 | 1/12 | ||
| 718747 | Hose Kit - V-200 20 | 7/05 | ||
| 718748 | Heat Option 12V | 1/12 | ||
| 718749 | Heat Option 24V | 1/12 | ||
| 719971 | Compressor DKS 15 12V | 1/12 | ||
| 719240 | Hose Kit - V-200 MAX-20 | 7/05 | ||
| 719241 | Hose Kit - V-200/V-190 MAX | 1/12 | ||
| 719268 | MAC 12V | 1/12 | ||
| 719599 | MAC 24V | 1/12 | ||
| 719972 | Compressor TM16-XD 2A 12V | 7/05 | ||
| 719973 | Compressor TM16-XD 2A 24V | 7/05 | ||
| 719974 | Compressor TM15-XD 2A 12V | 7/05 | ||
| 719975 | Compressor TM15-XD 2A 24V | 7/05 | ||
| 719976 | Compressor TM13-XD 2A 12V | 7/05 | ||
| 719977 | Compressor TM13-XD 2A 24V | 7/05 | ||
| 719978 | Compressor TM13-XD Poly 8 12V | 7/05 | ||
| 719979 | Compressor TM13-XD Poly 8 24V | 7/05 | ||
| 719980 | Compressor TM15-XD Poly 8 12V | 7/05 | ||
| 719981 | Compressor TM15-XD Poly 8 24V | 7/05 | ||
| 719982 | Compressor TM16-XD Variable 12V | 7/05 | ||
| 719983 | Compressor TM16-XD Variable 24V | 7/05 | ||
| 719984 | Compressor TM13-HA 12V | 7/05 | ||
| 719985 | Compressor TM08-XD 2A 12V | 7/05 | ||
| 719986 | Compressor TM15-XD Variable 12V | 7/05 | ||
| 720271 | Compressor Fittings | 1/12 | ||
| 720466 | Compressor TK-208R 12V 2 | 1/12 | ||
| 720677 | Water Heat Option | 1/12 | ||
| 720679 | Heater Kit - V-200/300 115V 12V | 7/05 | ||
| 720680 | Heater Kit - V-200/300 230V 12V | 7/05 |
