Установкa Thermo King V-200 Series схема REMOTE POWER RECEPTACLE – 269A8
Обновление от: 4/15/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 41-8292 | BOX - receptacle | 1 | |
| 2 | 42-301 | RECEPTACLE - power 250/1/30 | 1 | |
| 3 | 41-8293 | RECEPTACLE - power 250/3/30 | 1 | |
| 4 | 42-1101 | RECEPTACLE - power 125/1/30 | 1 | |
| 5 | 42-355 | PLUG - power 250/1/30 | 1 | |
| 6 | 42-356 | PLUG - power 250/3/30 | 1 | |
| 7 | 42-1003 | PLUG - power 125/1/30 | 1 |
