Установкa Thermo King V-200 MAX TC SAFEWAY схема JET COOL (V-200 MAX TC) – 189G5
Обновление от: 8/31/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 44-9020 | SWITCH - thermo (jet cool) | 1 | |
| 2 | 66-5029 | ORIFICE - jet cool | 1 | |
| 66-5028 | FILTER | 1 | ||
| 3 | 11-7777 | VALVE (Schrader) | 1 | |
| 4 | 51-2437 | FITTING - elbow (#4) | 1 | |
| 5 | 51-2465 | FITTING - straight (#4) | 2 | |
| 6 | 33-1461 | O-RING (#4) | 4 | |
| 7 | 102-811 | COMPRESSOR - TK 208R | 1 | |
| 107-339 | CLUTCH (8V groove, 12V) | 1 | ||
| 8 | 51-2434 | FITTING - discharge (45 degree, see 165D5) | 1 | |
| 11-7777 | VALVE (Schrader) | 1 | ||
| 9 | 51-2444 | FITTING - suction (90 degree, see 165D5) | 1 | |
| 11-7777 | VALVE (Schrader) | 1 | ||
| 10 | 33-566 | O-RING (#8) | 1 | |
| 11 | 33-2115 | O-RING (#10) | 1 | |
| 12 | 61-627 | HOSE - discharge (#8, see 165D6) | 1 | |
| 13 | 61-637 | HOSE - suction (#10, see 165D6) | 1 | |
| 14 | 67-1782 | HOSE - liquid injection & jet cool (#4, see 165D6) | 1 | |
| 15 | 51-2429 | SPLICE (#10 hose w/ 7/16-20 charging port) | 1 | |
| 16 | 92-3331 | BRACKET - pack | 1 | |
| 17 | 92-3332 | SHIELD - hose | 1 |
