Установкa Thermo King V-190 & V-190 MAX схема EVAPORATOR COMPONENTS (ES200) – 169G7
Обновление от: 7/19/11
| № | TK # | Описание | Кол-во Цена |
|---|---|---|---|
| 1 | 67-2610 | COIL - evaporator (E970) | 1 |
| 2 | 33-3135 | GROMMET (35 mm dia) | 7 |
| 3 | 61-1261 | FILTER - expansion valve | 1 |
| 4 | 66-9314 | BODY - expansion valve (V-190 MAX) | 1 |
| 66-9314 OEM | ТРВ, V/VM-Series MAX (R404A) | 30 490 ₽ |
| 66-9311 | BODY - expansion valve (V-190) | 1 | |
| 5 | 41-3136 | SWITCH - defrost | 1 |
| 55-9488 | SCREW - switch | 2 | |
| 6 | 41-3143 | SENSOR - temperature (w/ connector) | 1 |
| 55-9825 | CLAMP - sensor | 1 | |
| 55-9452 | SCREW - clamp | 1 | |
| 55-7697 | FLATWASHER | 2 | |
| 55-7861 | LOCKWASHER | 1 | |
| 55-7698 | NUT | 1 | |
| 7 | 44-8030 | SWITCH - lpco | 1 |
| 44-8030 OEM | Выключатель аварийный низкого давления | 15 830 ₽ |
| 8 | 78-1181 | FAN - special (225 mm, 12V) | 2 |
| 78-1182 | FAN - special (225 mm, 24V) | 2 | |
| 9 | 92-596 | SCREEN - fan | 2 |
| 55-7407 | SCREW - fan & screen | 8 | |
| 55-9826 | FLATWASHER | 16 | |
| 55-7404 | LOCKWASHER | 8 | |
| 55-7367 | NUT | 8 | |
| 10 | 98-5823 | COVER - evaporator | 1 |
| 55-7366 | SCREW - cover | 7 | |
| 55-7404 | LOCKWASHER | 7 | |
| 55-7089 | FLATWASHER | 7 |
