Установкa Thermo King UT-800 схема COOLING GROUP – 256G4
Обновление от: 8/7/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 67-2850 | RADIATOR | 1 | |
| 55-7035 | SCREW - coil | 8 | ||
| 55-6995 | FLATWASHER | 8 | ||
| 2 | 13-1175 | HOSE - expansion tank to radiator | 1 | |
| 3 | 55-3401 | CLAMP - hose (1.0 - 1.5 inch id) | 4 | |
| 55-6854 | CLAMP - hose (.88 - 1.25 inch id) | 2 | ||
| 4 | 13-1283 | HOSE - expansion tank to engine | 1 | |
| 5 | 13-1174 | HOSE - inlet (radiator to engine) | 1 | |
| 6 | 13-1173 | HOSE - outlet (engine to radiator) | 1 | |
| 7 | 13-418 | COVER - thermostat (see 185F9) | 1 | |
| 8 | 55-2796 | CLAMP - hose (.22 - .63 inch id) | 3 | |
| 9 | 13-1172 | TANK - overflow | 1 | |
| 10 | 11-5406 | CAP - radiator | 1 | |
|
10-11-5406 | Крышка радиатора | 2 200 ₽ |
|
| 51-2175 | SCREW - tank | 3 | ||
| 55-9762 | NUT | 3 | ||
| 11 | 41-2842 | SENSOR - coolant level | 1 | |
| 51-718 | SCREW - tank | 3 | ||
| 12 | 98-935 | HOSE - overflow (cut to length) | A/R | |
| 13 | 41-6538 | SENSOR - water temperature | 1 | |
|
10-41-6538 | Сенсор температуры двигателя, SLX/SB-XXX | 18 500 ₽ |
|
|
PP-41-6538 | Сенсор температуры двигателя, SLX/SB-XXX | 3 210 ₽ |
|
| 14 | 55-8653 | ELBOW - hose | 1 | |
| 15 | 92-9465 | DOOR - expansion tank | 1 | |
| 55-9461 | SCREW - door | 2 | ||
| 55-7112 | WASHER | 2 | ||
| 16 | 92-9466 | HINGE- door | 2 | |
| 51-2175 | SCREW - hinge | 8 |
