Установкa Thermo King UT-800 схема RECEIVER TANK ASSEMBLY – 256G1
Обновление от: 6/1/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 67-2677 | TANK - receiver | 1 | |
| 2 | 55-1983 | CAP - elbow (valve outlet) | 1 | |
| 3 | 66-2852 | CAP - service valve | 1 | |
| 4 | 66-9257 | BALL - liquid level | 1 | |
| 5 | 33-2419 | O-RING | 1 | |
| 6 | 67-2668 | INDICATOR - level (sight glass) | 1 | |
| 7 | 33-1015 | O-RING - relief valve | 1 | |
| 33-1015 OEM | О-ринг фильтра-осушителя, 3/8" | 240 ₽ |
|
|
| 8 | 66-7392 | VALVE - relief | 1 | |
|
10-66-7392 | Предохранительный клапан | 3 480 ₽ |
|
| PP-66-7392 | Предохранительный клапан | 1 730 ₽ |
|
|
| 9 | 66-7844 | ELBOW - outlet | 1 | |
| 10 | 92-9463 | BRACKET - tank | 1 | |
| 55-289 | NUT - tank | 2 | ||
| 55-2363 | LOCKWASHER | 2 | ||
| 55-2641 | FLATWASHER | 2 | ||
| 55-1800 | LOCKWASHER | 4 | ||
| 55-9761 | SCREW - bracket | 4 |
