Установкa Thermo King UMD 20DG схема OIL SYSTEM & GEAR COVER – 56A7
Обновление от: 7/6/04
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 11-5488 | PUMP - oil | 1 | |
|
10-11-5488 | Масляный насос, Yanmar 235, 353 | 29 540 ₽ |
|
| 2 | 55-4636 | PIN | 2 | |
| 3 | 33-1519 | GASKET | 1 | |
| 4 | 55-4637 | BOLT | 3 | |
| 55-4638 | WASHER | 3 | ||
| 5 | 33-1523 | GASKET | 1 | |
| 6 | 33-1524 | GASKET | 1 | |
| 7 | 55-4645 | BOLT | 1 | |
| 8 | Not Used | |||
| 9 | Not Used | |||
| 10 | 55-1140 | SCREW (hh cap) | 1 | |
| 55-4613 | WASHER | 1 | ||
| 11 | 11-5489 | RETAINER - pipe oil | 1 | |
| 12 | 11-5118 | PIPE | 1 | |
| 13 | 55-4733 | WASHER | 1 | |
| 14 | 55-4644 | BOLT | 1 | |
| 15 | 11-5481 | BEARING - ball | 1 | |
|
10-11-5481 | Подшипик, передний, Yanmar 235, 353 | 2 650 ₽ |
|
| 16 | 11-5116 | JOINT | 1 | |
| 17 | 11-5478 | PAN - oil sump | 1 | |
| 18 | 11-5184 | RETAINER | 1 | |
| 19 | 55-4752 | LOCKWASHER | 2 | |
| 20 | 55-4753 | SCREW | 2 | |
| 21 | Not Used | |||
| 22 | 11-6182 | FILTER - oil | 1 | |
|
11-6182 OEM | Фильтр масляный, Yanmar кроме 4XX, MD/RD/KD/T-Series | 2 820 ₽ |
|
|
US-11-6182 | Фильтр масляный, Yanmar кроме 4XX, MD/RD/KD/T-Series | 1 200 ₽ |
|
|
10-11-6182 | Фильтр масляный, Yanmar кроме 4XX, MD/RD/KD/T-Series | 630 ₽ |
|
| 23 | Not Used | |||
| 24 | 11-5045 | VALVE | 1 | |
| 25 | NSS | RETAINER | 1 | |
| 26 | NSS | BODY | 1 | |
| 27 | NSS | BALL | 1 | |
| 28 | NSS | SPRING | 1 | |
| 29 | NSS | SHIM | 1 | |
| 30 | 55-4642 | NUT | 1 | |
| 31 | 11-5480 | HOUSING - gear | 1 | |
| 32 | 55-4593 | PLUG | 1 | |
| 33 | 55-4646 | BOLT | 4 | |
| 55-4608 | LOCKWASHER | 4 | ||
| 34 | 11-5175 | COVER | 1 | |
| 35 | 33-1508 | GASKET | 1 | |
| 36 | 55-4621 | NUT | 4 | |
| 55-4622 | WASHER | 4 | ||
| 37 | 55-4620 | STUD | 4 | |
| 38 | 55-4648 | BOLT | 5 | |
| 39 | 55-4628 | BOLT | 1 | |
| 40 | 55-4649 | BOLT | 3 | |
| 55-4650 | BOLT | 1 | ||
| 41 | 55-4647 | BOLT | 2 | |
| 55-4613 | WASHER | 11 | ||
| 42 | 33-1509 | SEAL - oil | 1 | |
|
10-33-1509 | Сальник коленвала передний, Yanmar 235 / 353 | 1 800 ₽ |
|
| 43 | 55-4646 | BOLT | 2 | |
| 55-4607 | FLATWASHER | 2 | ||
| 44 | 13-933 | COVER | 1 | |
| 45 | 33-1511 | O-RING | 1 | |
| 46 | 33-3938 | GASKET | 1 | |
| 47 | 55-4643 | PLUG | 1 | |
| 30-174 | GASKET SET - overhaul | 1 | ||
|
10-30-174 | Набор прокладок, Yanmar 235, KD/MD/RD-I | 16 910 ₽ |
|
