Установкa Thermo King TriPac e схема INVERTER GROUP (073003) – 244D1
Обновление от: 6/20/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 45-2341 | INVERTER (1000W DC/AC) | 1 | |
| 2 | 40-1075 | CABLE KIT | 1 | |
| 42-919 | CABLE - battery (positive 168 inch) | 1 | ||
| 42-920 | CABLE - battery (negative 180 inch) | 1 | ||
| 42-921 | CABLE - battery (negative 120 inch) | 1 | ||
| 41-8598 | TERMINAL - lug (3/8, 2 awg) | A/R | ||
| 41-8854 | TERMINAL - lug (1/4, 8 awg) | A/R | ||
| 41-5670 | CAP - insulator (red) | 1 | ||
| 41-9402 | CAP - insulator (black) | 1 | ||
| 3 | 41-7008 | HOLDER - fuse | 1 | |
| 30-41-7008 | Гнездо предохранителя | 1 820 ₽ |
|
|
| 4 | 41-8486 | FUSE (150 amp) | 1 | |
| 5 | 55-2977 | SCREW - holder | 2 | |
| 55-2086 | FLATWASHER | 4 | ||
| 55-4953 | NUT | 2 |
