Установкa Thermo King TriPac e схема EVAPORATOR REFRIGERATION – 242E2
Обновление от: 4/9/10
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 67-2464 | COIL - evaporator | 1 | |
| 2 | 99-4976 | STRIP - neoprene | A/R | |
| 3 | 33-1015 | O-RING (#6) | 1 | |
| 33-1015 OEM | О-ринг фильтра-осушителя, 3/8" | 240 ₽ |
|
|
| 4 | 51-1999 | ADAPTER - nut (#6) | 1 | |
| 5 | 61-5086 | TUBE - adapter to heat exchanger adapter | 1 | |
| 6 | 67-2465 | HEAT EXCHANGER | 1 | |
| 7 | 92-4439 | TUBE - rubber | A/R | |
| 8 | 61-5087 | TUBE- heat exchange to expansion valve | 1 | |
| 9 | 61-5067 | VALVE - expansion | 1 | |
| 10 | 61-5089 | TUBE - coil to heat exchanger | 1 | |
| 11 | 61-5090 | TUBE - heat exchanger to compressor | 1 | |
| 12 | 61-5091 | FITTING - service port (suction) | 1 | |
| 61-5092 | VALVE (Schrader) | 1 | ||
| 61-5093 | CAP | 1 | ||
| 13 | 102-969 | COMPRESSOR (see 242H5) | 2 | |
| 55-2958 | FLATWASHER | 3 | ||
| 55-4954 | NUT - lock | 3 | ||
| 14 | 33-566 | O-RING (#8) | 1 | |
| 15 | 61-5094 | TUBE - discharge to adapter | 1 | |
| 16 | 55-9823 | ADAPTER - nut (#8) | 1 | |
| 66-3571 | FITTING - saddle | 1 | ||
| 17 | 61-5095 | FITTING - service port (discharge) | 1 | |
| 61-5096 | VALVE (Schrader) | 1 | ||
| 61-5097 | CAP | 1 | ||
| 18 | 41-9219 | SWITCH - hpco | 1 | |
| 203-393 | SEALER - thread | A/R | ||
| 19 | 91-1800 | CLAMP - tube | 4 | |
| 55-3121 | SCREW | 2 | ||
| 55-2086 | FLATWASHER | 4 | ||
| 55-4953 | NUT - lock | 2 |
