Установкa Thermo King TriPac e схема CONDENSER GROUP – 242E1
Обновление от: 4/12/10
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 98-5425 | GUARD - fan | 1 | |
| 2 | 78-1715 | FAN - condenser (see 115D14 for connector) | 1 | |
| 3 | 55-2979 | SCREW - fan | 4 | |
| 55-1800 | LOCKWASHER | 4 | ||
| 55-2086 | FLATWASHER | 4 | ||
| 55-8117 | WASHER - special | 4 | ||
| 4 | 92-8266 | FRAME - condenser (black) | 1 | |
| 92-8267 | FRAME - condenser (ss) | 1 | ||
| 55-8979 | INSERT (1/4-20) | 6 | ||
| 55-8752 | INSERT (10-32) | 4 | ||
| 5 | 55-3048 | SCREW | 6 | |
| 55-2363 | LOCKWASHER | 6 | ||
| 55-2641 | FLATWASHER | 6 | ||
| 55-4955 | NUT - lock | 6 | ||
| 6 | 67-2494 | COIL - condenser | 1 | |
| 55-3843 | SCREW - coil | 4 | ||
| 55-2964 | LOCKWASHER | 4 | ||
| 55-2001 | FLATWASHER | 4 | ||
| 7 | 92-8271 | BRACKET - dehydrator | 1 | |
| 55-2979 | SCREW | 2 | ||
| 55-1800 | LOCKWASHER | 2 | ||
| 55-2945 | WASHER - special | 2 | ||
| 8 | 51-1220 | CLAMP - dehydrator | 2 |
