Установкa Thermo King TriPac Tier 2 Engine (after 10/08) схема HOURMETER GROUP (Optional, Before 2/12) – 221F0
Обновление от: 1/11/08
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 45-2212 | KIT - hourmeter | 1 | ||
| 1 | 41-7785 | HARNESS - hourmeter | 1 | |
| 2 | 41-3074 | HOLDER - fuse | 3 | |
| 30-41-3074 | Гнездо предохранителя | 600 ₽ |
|
|
| 3 | 41-3077 | FUSE (3 amp) | 3 | |
| 30-41-3077 | Предохранитель 32V 3А | 520 ₽ |
|
|
| 4 | 33-1105 | GROMMET | 1 | |
| 5 | 92-6199 | CASE - hourmeter | 1 | |
| 55-4829 | SCREW - case | 4 | ||
| 6 | 92-6197 | PLATE - hourmeter (horizontal) | 1 | |
| 7 | 92-6198 | PLATE - hourmeter (vertical) | 1 | |
| 8 | 92-6200 | NAMEPLATE - Engine Hours | 1 | |
| 9 | 92-6201 | NAMEPLATE - Espar Hours | 1 | |
| 10 | 41-7250 | HOURMETER | 2 | |
| 11 | 55-7667 | PLUG - button | 2 |
