Установкa Thermo King TriPac Tier 1 Engine схема BELT & PULLEY GROUP – 212F5
Обновление от: 4/19/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 77-2860 | PULLEY - engine | 1 | |
| 108-2192 | SCREW - pulley | 5 | ||
| 55-5411 | LOCKWASHER | 5 | ||
| 203-400 | SEALER - thread | A/R | ||
| 2 | 78-1543 | BELT - compressor & alternator (poly groove) | 1 | |
| 20-78-1543 | Ремнь, TRI-Pac | 5 820 ₽ |
|
|
| 3 | 77-2846 | PULLEY - idler (Tier 1 engine) | 1 | |
| 51-1244 | SCREW - pulley | 1 | ||
| 55-365 | LOCKWASHER | 1 | ||
| 4 | 92-5510 | BRACKET - idler pulley | 1 | |
| 5 | 77-2845 | PULLEY - alternator | 1 | |
| 6 | 77-2844 | FAN - alternator | 1 | |
| 7 | 41-9856 | ALTERNATOR (65 amp, see 242H0) | 1 | |
| 51-1246 | SCREW - alternator | 1 | ||
| 55-4625 | FLATWASHER | 2 | ||
| 55-7005 | NUT | 1 | ||
| 8 | 92-5510 | BRACKET - alternator | 1 | |
| 9 | 92-5513 | PLATE - engine | 1 | |
| 10 | 92-5181 | BRACKET - compressor (rear) | 1 | |
| 11 | 92-5182 | BRACKET - compressor bracket to engine | 1 | |
| 55-1469 | SCREW - bracket (3/8) | 2 | ||
| 55-402 | FLATWASHER | 2 | ||
| 55-5078 | NUT | 2 | ||
| 12 | 92-5183 | SHIM - compressor | 1 | |
| 13 | 102-1018 | COMPRESSOR - 15HD (see 169C2) | 1 | |
| 14 | 107-311 | CLUTCH (12V, 4.62 in, poly groove, 8V) | 1 | |
|
10-107-261 | Муфта электромагнитная, 8PV/12V, TM13/15/16, QP13/15/16 | 7 740 ₽ |
|
| 55-3641 | SCREW - compressor | 4 | ||
| 55-402 | FLATWASHER | 8 | ||
| 55-5078 | NUT | 4 | ||
| 15 | 92-5015 | BARREL - turnbuckle | 1 | |
| 16 | 51-1223 | JOINT - hemi (left hand, 3/8-24 threads) | 1 | |
| 51-1214 | NUT (left hand, 3/8-24 threads) | 1 | ||
| 17 | 51-1222 | JOINT - hemi (7/16-20 threads) | 1 | |
| 55-2326 | NUT (7/16-20 threads) | 1 | ||
| 18 | 55-5075 | SCREW - engine mount | 4 | |
| 19 | 55-377 | FLATWASHER | 8 | |
| 20 | 91-2338 | MOUNT - engine | 4 | |
|
10-91-2338 | Подушка двигателя, CD/JD/KD/MD-II | 3 020 ₽ |
|
| 21 | 55-3054 | NUT | 4 | |
| 22 | 92-5504 | MOUNT - engine (front) | 1 | |
| 20-92-5504 | Опора | 13 510 ₽ |
|
|
| 23 | 92-5391 | MOUNT - engine (rear) | 1 | |
| 20-92-5391 | Опора | 13 920 ₽ |
|
|
| 55-8682 | SCREW - mount | 8 | ||
| 55-1173 | LOCKWASHER | 8 | ||
| 55-4625 | FLATWASHER | 8 |
