Установкa Thermo King TriPac EVOLUTION схема AIR CLEANER & MUFFLER – 269D3
Обновление от: 7/1/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 13-820 | AIR FILTER | 1 | |
| 2 | 11-9059 | ELEMENT - filter | 1 | |
|
US-11-9059 | Фильтр воздушный, MD/T-Series | 2 410 ₽ |
|
|
10-11-9059 | Фильтр воздушный, MD/T-Series | 740 ₽ |
|
| 55-5022 | SCREW - air filter | 2 | ||
| 55-790 | LOCKWASHER | 2 | ||
| 55-4613 | FLATWASHER | 2 | ||
| 3 | 13-651 | HOSE - air | 1 | |
| 4 | 55-3991 | CLAMP - hose | 3 | |
| 5 | 13-1656 | HOSE - air cleaner | 1 | |
| 6 | 93-1035 | BRACKET - air filter | 1 | |
| 55-5022 | SCREW - bracket | 4 | ||
| 55-4613 | FLATWASHER | 4 | ||
| 55-790 | LOCKWASHER | 4 | ||
| 7 | 33-4189 | GASKET - exhaust | 1 | |
| 8 | 13-463 | TUBE - exhaust | 1 | |
| 55-4621 | NUT - exhaust tube | 4 | ||
| 55-790 | LOCKWASHER | 4 | ||
| 55-4613 | FLATWASHER | 4 | ||
| 9 | 91-4611 | CLAMP - exhaust | A/R | |
| 10 | 12-442 | HOSE - exhaust (25 ft, cut to 24 inch) | A/R | |
| 11 | 12-913 | MUFFLER (stainless steel) | 1 | |
| 12 | 55-7800 | CLAMP - muffler | 2 | |
| 13 | 10-466 | KIT - exhaust pipe (409 ss) | 1 | |
| 10-465 | KIT - exhaust pipe (304 ss) | 1 | ||
| 14 | NSS | BRACKET - pipe | 1 | |
| 55-9761 | SCREW - bracket | 2 | ||
| 15 | 10-464 | PIPE - tail (409 ss) | 1 | |
| 10-465 | PIPE - tail (304 ss) | 1 | ||
| 16 | 99-496 | CLAMP - exhaust (1-5/8 id) | A/R |
