Установкa Thermo King TriPac EVOLUTION схема ELECTRICAL COMPONENTS – 269D0
Обновление от: 6/19/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 45-2539 | CONTROLLER | 1 | |
| 2 | 41-9382 | HARNESS - HMI | 1 | |
| 42-1189 | HARNESS - HMI (jumper) | 1 | ||
| 41-4734 | CONNECTOR (8-pin) | 2 | ||
| 41-5718 | TERMINAL (22-18 ga) | A/R | ||
| 3 | NSS | BOX - control (see 269E1) | 1 | |
| 4 | 42-1114 | HARNESS - main | 1 | |
| 5 | 42-1117 | HARNESS - A/C | 1 | |
| 6 | NSS | EVAPORATOR (see 269D9) | 1 | |
| 7 | 41-2113 | SWITCH - low pressure cutout | 1 | |
| 44-6263 | SWITCH - only | 1 | ||
| 8 | NSS | CONDENSER (see 269D8) | 1 | |
| 9 | 41-7509 | SWITCH - high pressure | 1 | |
| 44-8491 | SWITCH - only | 1 | ||
| 10 | 41-9378 | HARNESS - heater D2 | 1 | |
| 11 | 41-9374 | HEATER (D2 standard, see 231C6) | 1 | |
| 41-9375 | HEATER (D4 see 231E7) | 1 | ||
| 12 | 78-1535 | FAN - precool coil | 1 | |
| 13 | 42-1172 | HARNESS - standby ignition lead (option, w/ toggle switch) | 1 | |
| 14 | 42-1171 | HARNESS - standby ignition lead (option) | 1 | |
| 41-1770 | HOLDER - fuse | 1 | ||
| 30-41-1770 | Гнездо предохранителя 32V 30А | 760 ₽ |
|
|
| 15 | 44-490 | SWITCH - standby (toggle) | 1 | |
|
10-44-490 | Выключатель | 2 590 ₽ |
|
| 16 | 41-1932 | FUSE (1 amp) | 1 | |
| 41-1769 | COVER - fuse | 1 | ||
| 30-41-1769 | Крышка предохранителя | 510 ₽ |
|
|
| 17 | 40-1221 | KIT - sensor, temperature (120 amp alternator option) | 1 | |
| 18 | 42-1115 | CABLE - starter positive | 1 | |
| 19 | 41-7008 | HOLDER - fuse | 1 | |
| 30-41-7008 | Гнездо предохранителя | 1 820 ₽ |
|
|
| 20 | 41-9758 | FUSE - battery (200 amp) | 1 | |
| 21 | 41-7016 | CABLE - battery (positive, 12 inch) | 1 | |
| 22 | 41-7507 | CABLE - battery (negative, 240 inch) | 1 |
