Установкa Thermo King Telematics Products схема TRAC-KING SATELLITE 2-WAY TRAILER (Up-VI, 701312) – 226E0
Обновление от: 9/24/11
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 40-971 | KIT - TRAC-KING uP-VI 2-way | 1 | ||
| 1 | 45-2235 | MODEM - satellite (MT3550) | 1 | |
| 51-321 | RIVET - modem | 2 | ||
| 2 | 41-8181 | HARNESS - modem | 1 | |
| 3 | 44-8920 | PLUG (6-pin) | 2 | |
| 4 | 99-6093 | MOUNT - harness | A/R | |
| 51-321 | RIVET - mount | A/R | ||
| 55-2332 | BANDWRAP (3/4 dia) | A/R | ||
| 55-2331 | BANDWRAP (4.0 dia) | A/R | ||
| 5 | 92-2751 | NAMEPLATE - Warning, Satellite Control & Switch (set) | 1 | |
| 6 | 92-2752 | NAMEPLATE - Switch | 1 | |
| 7 | 41-5840 | HARNESS - control box | 1 | |
| 8 | 44-8915 | PLUG - power supply (4-pin) | 1 | |
| 9 | 41-5190 | PLUG - electric (35 terminal, white) | 1 | |
| 10 | 41-2405 | RECEPTACLE - flash loading (5-pin) | 1 | |
| 11 | 44-9342 | PLUG - controller | 1 | |
| 12 | 44-8914 | RECEPTACLE (6 terminal) | 2 | |
| 13 | 44-8920 | PLUG (6 terminal) | 2 | |
| 14 | 41-5217 | HARNESS - switch | 1 | |
| 44-5622 | CONNECTOR - electric (6-pin, female) | 1 | ||
| 15 | 41-5329 | SWITCH - push button (green) | 1 | |
| 16 | 41-5330 | SWITCH - push button (red) | 1 | |
| 17 | 41-4163 | SWITCH - on/off | 1 | |
|
30-41-4163 | Выключатель | 5 410 ₽ |
|
| 18 | 41-4165 | SWITCH - on/none/on (satellite) | 1 | |
| 19 | 44-5537 | SOCKET - relay | 1 | |
| 20 | 41-8114 | HARNESS - jumper | 1 | |
| 21 | 41-895 | RELAY - plug-in | 1 | |
|
30-41-895 | Реле | 1 650 ₽ |
|
| 22 | 45-2355 | iBox (see 191H7) | 1 | |
| 51-320 | SCREW | 3 | ||
| 55-3013 | FLATWASHER | 3 | ||
| 51-114 | STANDOFF | 3 | ||
| 55-2998 | WASHER | 3 | ||
| 23 | 41-5839 | HARNESS - relay (iBox) | 1 | |
| 24 | 33-3369 | RING - sealing | 2 |
