Установкa Thermo King TS-200 w/TK 370 Engine схема DOOR GROUP – 214B0
Обновление от: 10/20/09
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 98-7018 | DOOR - curbside (incl latch, hinges and insulation, before 6/09) | 1 | |
| 2 | 92-2991 | LATCH - door (before 6/09) | 1 | |
|
10-92-2991 | Замок двери, New MD & TS | 12 190 ₽ |
|
| 3 | 33-4077 | INSULATION - curbside door (before 6/09) | 1 | |
| 4 | 92-4483 | TRIM - door edge | A/R | |
| 5 | 92-2990 | HINGE - door | 4 | |
| 55-1587 | SCREW - hinge | 8 | ||
| 55-1800 | LOCKWASHER | 8 | ||
| 55-2086 | FLATWASHER | 8 | ||
| 55-8711 | INSERT - threaded | 8 | ||
| 6 | 92-5536 | HINGE - door | 4 | |
| 7 | 51-1119 | SCREW - hinge | 4 | |
| 55-7339 | NUT | 4 | ||
| 8 | 92-1105 | BOLTSTRIP | 4 | |
| 55-4953 | NUT - hinge | 8 | ||
| 55-2086 | FLATWASHER | 8 | ||
| 9 | 92-5705 | BRACKET - door latch (before 6/09) | 1 | |
| 55-2977 | SCREW - bracket | 2 | ||
| 55-1800 | LOCKWASHER | 1 | ||
| 55-2086 | FLATWASHER | 2 | ||
| 55-4953 | NUT | 1 | ||
| 10 | 98-7512 | DOOR - top | 1 | |
| 11 | 33-4290 | INSULATION - top door | 1 | |
| 12 | 51-1116 | SCREW - top door | 2 | |
| 55-2958 | FLATWASHER | 2 | ||
| 51-1117 | RETAINER - screw | 2 | ||
| 13 | 55-6544 | CLAMP - hinge | 4 | |
| 14 | 55-7781 | SCREW - clamp | 4 | |
| 55-2086 | FLATWASHER | 4 | ||
| 55-1800 | LOCKWASHER | 4 | ||
| 55-8782 | WASHER - special | 4 | ||
| 15 | 92-4480 | BUMPER - mount | 2 | |
| 16 | 33-4287 | BLOCK - prop rod | 1 | |
| 17 | 92-4482 | ROD - prop (door) | 1 | |
| 18 | 55-6416 | CAP - rod | 1 | |
| 19 | 92-4484 | BRACKET - switch | 1 | |
| 55-2977 | SCREW - bracket | 3 | ||
| 55-1800 | LOCKWASHER | 3 | ||
| 55-2086 | FLATWASHER | 3 | ||
| 55-9440 | NUT - speed | 3 | ||
| 20 | 98-7017 | DOOR - roadside (incl hinges & door screws) | 1 | |
| 21 | 92-4483 | TRIM - edge | A/R | |
| 22 | 99-7246 | STRIP - seal | A/R | |
| 23 | 55-9330 | SCREW - door | 2 | |
| 305-1423 | WASHER (nylon) | 2 | ||
| 55-8782 | WASHER - special | 2 | ||
| 55-9440 | NUT - speed (U) | 2 | ||
| 24 | 98-8402 | DOOR - curbside (incl latches, hinges and insulation, 6/09 & After) | 1 | |
| 25 | 33-4540 | INSULATION - curbside door (6/09 & After) | 1 | |
| 26 | 55-8779 | FASTENER - door (6/09 & After) | 2 | |
| 27 | 51-1117 | RETAINER - door (6/09 & After) | 2 | |
| 28 | 92-8093 | PANEL - blockoff (6/09 & After) | 1 | |
| 29 | 55-4318 | NUT - u (6/09 & After) | 2 | |
|
20-55-4318 | Крепеж | 1 730 ₽ |
|
| 30 | 92-2895 | PANEL - blockoff ( before 6/09) | 1 |
