Установкa Thermo King TNE 405 D & E схема REFRIGERATION - FRONT VIEW (YORK TNE 405 D & E) – 150F8
Обновление от: 12/17/98
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 509-172 | GRILLE - side air inlet (060-07300) | 2 | |
| 2 | 509-639 | SCREEN - return air inlet (360-07419) | 2 | |
| 3 | 509-163 | PANEL - top (060-07237) | 1 | |
| 4 | 509-1559 | DOOR - right side (060-07240) | 1 | |
| 5 | 509-1560 | DOOR - left side (060-07241) | 1 | |
| 6 | 509-1656 | LATCH - doors (K29-15478) | 7 | |
| 7 | 509-100 | HINGE - left side (K29-17879) | 1 | |
| 8 | 509-1005 | HINGE - right side (K29-17880) | 1 | |
| 9 | 509-168 | SEAL - hinge (rightside door) (060-07251) | 1 | |
| 10 | 509-169 | SEAL - hinge (leftside door) (060-07252) | 1 | |
| 11 | 509-192 | PANEL - bottom (060-07674) | 1 | |
| 12 | 33-3055 | GASKET - unit seal, top & bottom (060-07415-01) | 2 | |
| 13 | 33-3056 | GASKET - unit seal, both sides (060-07415-02) | 2 |
