Установкa Thermo King TNE 405 D & E схема REFRIGERATION - REAR VIEW (YORK TNE 405 D01) – 150F10
Обновление от: 5/2/09
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 509-1114 | NAMEPLATE - Datalogger (K35-51543) | 1 | |
| 2 | 509-1656 | LATCH - doors (K29-15478) | 1 | |
| 3 | 91-9131 | DOOR (060-51077) | 1 | |
| 4 | 509-1009 | SEAL - hinge (K29-18483) | 1 | |
| 5 | 91-9132 | PANEL - bottom (060-51076) | 1 | |
| 6 | 91-9133 | PANEL - middle (060-51075) | 1 | |
| 7 | 91-9134 | PANEL - top (060-51113) | 1 | |
| 8 | 509-1112 | NAMEPLATE - PT 100 No. 1 (K35-51541) | 2 | |
| 10 | 504-1458 | SOCKET - complete (with cable) (K25-52155) | 2 | |
| 11 | 509-1113 | NAMEPLATE - PT 100 No. 2 (K35-51542) | 2 | |
| 12 | 41-3588 | CAP (K28-52070) | 2 | |
| 13 | 55-9180 | SPACER - air spacer (060-07261) | 2 | |
| 14 | 55-9181 | SPACER - air spacer center (060-07260) | 3 |
