Установкa Thermo King TNE 405 A, B, C схема REAR VIEW REFRIGERATION (TNE 405A) – 150F3
Обновление от: 8/31/99
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 509-172 | GRILLE - side air inlet (060-07300) | 2 | |
| 2 | 509-639 | SCREEN - return air inlet (360-07419) | 2 | |
| 3 | 91-9111 | PANEL - top (060-08013) | 1 | |
| 4 | 91-9112 | PANEL - rear evaporator support (060-08012) | 1 | |
| 5 | 91-9113 | PANEL - air flue (060-08011) | 1 | |
| 6 | 33-3056 | GASKET - unit seal, both sides (060-07415-02) | 2 | |
| 7 | 33-3055 | GASKET - unit seal, top & bottom (060-07415-01) | 2 | |
| 8 | 91-9114 | PANEL - air flue (060-08010) | 1 | |
| 9 | 91-9115 | PLATE - suction valve access (060-08014) | 1 |
