Установкa Thermo King TH11-M10 схема EVAPORATOR BLOWER – 178A3
Обновление от: 5/22/10
| № | TK # | Описание | Кол-во Цена |
|---|---|---|---|
| 1 | 98-4625 | TRAY - evaporator motor | 1 |
| 55-2969 | SCREW - tray | 12 | |
| 55-2958 | FLATWASHER | 12 | |
| 55-2959 | LOCKWASHER | 12 | |
| 55-9159 | INSERT - threaded | 12 | |
| 2 | 77-2664 | BEARING - flange | 2 |
| 55-2341 | SCREW - flange | 4 | |
| 55-4931 | WASHER - special | 4 | |
| 55-2641 | FLATWASHER | 4 | |
| 55-4955 | NUT | 4 | |
| 3 | 99-7780 | SPACER - motor mount | 1 |
| 4 | 104-323 | MOTOR - evaporator blower (see 76C1) | 1 |
| 55-3490 | SCREW - motor | 4 | |
| 55-4727 | FLATWASHER | 4 | |
| 55-2959 | LOCKWASHER | 4 | |
| 55-8976 | INSERT | 4 | |
| 5 | 77-2589 | COUPLING - flexible | 2 |
| 6 | 77-2665 | SHAFT - motor | 2 |
| 7 | 77-2519 | WHEEL - blower (ccw) | 1 |
| 8 | 77-2518 | WHEEL - blower (cw) | 1 |
| 9 | 98-7383 | HOUSING - blower (curbside) | 1 |
| 10 | 98-7382 | HOUSING - blower (roadside) | 1 |
| 55-2979 | SCREW - housing | 2 | |
| 55-4953 | LOCKNUT (1/4-20) | 2 | |
| 55-3031 | SCREW - housing | 10 | |
| 55-2001 | FLATWASHER | 10 | |
| 55-4560 | LOCKNUT (10-32) | 10 | |
| 55-2965 | NUT (10-32) | 10 | |
| 11 | 99-9316 | PLATE - blower housing cover | 2 |
| 55-3669 | RIVET - plate | 10 | |
| 12 | 92-1295 | FLANGE - transition | 2 |
| 55-2988 | RIVET - flange | 12 | |
| 13 | 92-761 | SPACER - bearing | 4 |
| 14 | 77-1834 | RING - inlet | 2 |
| 55-4560 | LOCKNUT (10-32) | 10 |
