Установкa Thermo King TEA14-M1 схема INVERTER – 249A9
Обновление от: 10/29/10
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 92-8734 | PANEL - enclosure | 1 | |
| 55-2957 | SCREW - panel | 4 | ||
| 55-1800 | LOCKWASHER | 4 | ||
| 55-2086 | FLATWASHER | 4 | ||
| 55-8711 | INSERT | 4 | ||
| 2 | 99-8562 | STRIP - neoprene (25 ft long) | A/R | |
| 3 | 92-8735 | COVER | 1 | |
| 55-2957 | SCREW - cover | 4 | ||
| 55-1800 | LOCKWASHER | 4 | ||
| 55-2086 | FLATWASHER | 4 | ||
| 55-8711 | INSERT | 4 | ||
| 4 | 45-2360 | INVERTER - control box | 1 | |
| 55-3000 | SCREW - inverter | 4 | ||
| 55-2964 | LOCKWASHER | 4 | ||
| 55-2001 | FLATWASHER | 4 | ||
| 55-8798 | INSERT | 4 | ||
| 5 | 51-2046 | CONNECTOR - harness grip | 1 | |
| 51-2047 | WASHER | 1 | ||
| 51-2048 | NUT | 1 | ||
| 6 | 51-2049 | CONNECTOR - harness grip | 4 | |
| 51-2050 | WASHER | 4 | ||
| 51-2051 | NUT | 4 | ||
| 7 | 51-2043 | CONNECTOR - harness grip | 1 | |
| 51-2044 | WASHER | 1 | ||
| 51-2045 | NUT | 1 | ||
| 8 | 41-4188 | CONNECTOR - harness grip | 1 | |
| 41-4189 | WASHER | 1 | ||
| 55-2636 | NUT | 1 |
