Установкa Thermo King TEA1-M2 схема INSULATION GROUP – 246H6
Обновление от: 7/7/10
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 99-6882 | INSULATION - floor (lower) | 1 | |
| 2 | 99-6998 | INSULATION - floor (lower) | 1 | |
| 3 | 99-6881 | INSULATION - floor (lower) | 2 | |
| 4 | 33-4691 | INSULATION - floor (condenser floor) | 1 | |
| 5 | 33-4692 | INSULATION - back (roadside) | 1 | |
| 6 | 33-4469 | INSULATION - back (curbside) | 1 | |
| 7 | 33-4693 | INSULATION - back (middle) | 1 | |
| 8 | 33-4694 | INSULATION - panel (top) | 1 | |
| 9 | 33-4473 | INSULATION - panel (roadside) | 1 | |
| 10 | 33-4474 | INSULATION - panel (curbside) | 1 | |
| 11 | 33-4695 | INSULATION - back (middle) | 1 |
