Установкa Thermo King TEA1-M2 схема REFRIGERATION CONDENSER – 246G3
Обновление от: 7/30/10
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 102-990 | COMPRESSOR - scroll (see 246G7) | 2 | |
| 2 | 61-5242 | TUBE - compressor to coil (#1) | 1 | |
| 66-9842 | VALVE | 1 | ||
| 3 | 61-5243 | TUBE - compressor to tube (#2) | 1 | |
| 66-9842 | VALVE | 1 | ||
| 66-3571 | FITTING - saddle | 2 | ||
| 4 | 41-4486 | SWITCH - hpco | 2 | |
| 5 | 41-7956 | TRANSDUCER - discharge | 2 | |
| 6 | 61-5244 | TUBE - discharge, tube to condenser | 1 | |
| 7 | 67-2515 | COIL - condenser | 1 | |
| 55-8711 | INSERT | 5 | ||
| 99-5966 | STRIP - neoprene | A/R | ||
| 92-2310 | SEALER - tape (1 in wide) | A/R | ||
| 8 | 61-5245 | TUBE - condenser to dehydrator (#1) | 1 | |
| 9 | 61-5246 | TUBE - condenser to dehydrator (#2) | 1 | |
| 10 | 61-600 | DEHYDRATOR | 2 | |
|
US-61-600 | Дегидратор, SL/SLe/SLX/SLXe/SMX/SMX-II/SB / UT-800/1200 | 8 100 ₽ |
|
|
PP-61-600 | Дегидратор, SL/SLe/SLX/SLXe/SMX/SMX-II/SB / UT-800/1200 | 2 490 ₽ |
|
| 11 | 55-7800 | CLAMP - dehydrator | 4 | |
| 12 | 91-758 | CLAMP - tube | 3 | |
| 13 | 91-759 | CLAMP - tube | 3 | |
| 55-3675 | SCREW - clamp | 6 | ||
| 55-1800 | LOCKWASHER | 6 | ||
| 55-2086 | FLATWASHER | 6 | ||
| 14 | 33-1809 | GROMMET (.50 id) | 2 | |
| 15 | 66-7392 | VALVE - relief (see 119B8) | 2 | |
|
10-66-7392 | Предохранительный клапан | 3 480 ₽ |
|
| PP-66-7392 | Предохранительный клапан | 1 730 ₽ |
|
