Установкa Thermo King TE1-M3 схема INSULATION GROUP – 231B8
Обновление от: 11/14/08
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 99-6882 | INSULATION - floor (lower) | 1 | |
| 2 | 99-6998 | INSULATION - floor (lower) | 1 | |
| 3 | 99-6881 | INSULATION - floor (lower) | 2 | |
| 4 | 33-4468 | INSULATION - floor (condenser floor) | 1 | |
| 5 | 33-4470 | INSULATION - back (curbside) | 1 | |
| 6 | 33-4469 | INSULATION - back (roadside) | 1 | |
| 7 | 33-4471 | INSULATION - back (middle) | 1 | |
| 8 | 33-4472 | INSULATION - panel (top) | 1 | |
| 9 | 33-4473 | INSULATION - panel (roadside) | 1 | |
| 10 | 33-4474 | INSULATION - panel (curbside) | 1 |
