Установкa Thermo King TDD-M2 Northern Double Deck схема HARNESS CONDENSER – 240A9
Обновление от: 9/14/09
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 41-6727 | HARNESS - condenser | 1 | |
| 2 | 44-5835 | CONNECTOR - shroud (2-pin) | 1 | |
| 44-5883 | TERMINAL - male (18-20 ga) | 2 | ||
| 44-5885 | SEAL - cable (green, 18-22 ga) | 2 | ||
| 3 | 44-2792 | TERMINAL - ring (yellow #10) | 1 | |
| 4 | 41-8841 | TERMINAL (14-16 awg) | 6 | |
| 5 | 55-2635 | NUT - lock | 1 | |
| 6 | 41-6950 | CONNECTOR - liquid tite | 1 | |
| 41-3123 | HEATSHRINK | 1 | ||
| 7 | 44-5089 | TERMINAL - ring (yellow 3/8) | 4 | |
| 8 | 44-7881 | CONNECTOR - tower (4-pin) | 6 | |
| 44-5884 | TERMINAL - female (18-20 ga) | 12 | ||
| 44-5885 | SEAL - cable (green, 18-22 ga) | 12 | ||
| 44-5839 | TERMINAL - female (14-16 ga) | 12 | ||
| 44-6324 | SEAL - cable (blue, 12-14 ga) | 12 | ||
| 9 | 41-1789 | CONNECTOR - tower (6-pin) | 4 | |
| 41-4229 | TERMINAL - female (16 ga) | 18 | ||
| 44-5885 | SEAL - cable (green, 18-22 ga) | 18 | ||
| 44-7812 | PLUG - cavity (green) | 6 | ||
| 10 | 41-1790 | LOCK - secondary | 4 | |
| 11 | 41-1788 | BUSBAR | 4 | |
| 12 | 41-1787 | COVER - connector | 4 | |
| 41-7680 | HEATSHRINK | A/R |
