Установкa Thermo King TDD-M1 Southern Double Deck схема DRIVE KIT 701024 - Alex Dennis E500 ISM07, S616 2-5 V Pulleys – 227F7
Обновление от: 8/19/09
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 108-2596 | BRACKET - assembly | 1 | |
| 2 | 108-2450 | BOLT - bracket | 7 | |
| 3 | 51-145 | WASHER - conical | 16 | |
| 4 | 108-1588 | NUT | 13 | |
| 5 | 108-2597 | PLATE - assembly | 1 | |
| 6 | 55-4723 | SCREW - plate | 9 | |
| 7 | 92-2963 | SILENTBLOCK | 6 | |
| 8 | 55-5424 | SCREW - silentblock | 18 | |
| 9 | 55-7069 | FLATWASHER | 36 | |
| 10 | 108-1594 | NUT | 18 | |
| 11 | 108-2598 | PLATE - assembly | 1 | |
| 12 | 51-1637 | SCREW - silentblock to plate | 6 | |
| 13 | 55-5914 | FLATWASHER | 12 | |
| 14 | 92-4472 | PLATE - threaded | 2 | |
| 15 | 108-2548 | TENSIONER | 1 | |
| 16 | 108-1601 | PULLEY - complete | 1 | |
| 108-1602 | PULLEY | 1 | ||
| 108-1603 | BEARING | 2 | ||
| 51-778 | RING | 1 | ||
| 108-1604 | RING - retain | 1 | ||
| 17 | 55-6280 | SCREW - pulley | 1 | |
| 18 | 51-144 | WASHER - conical | 2 | |
| 19 | 108-1607 | FLATWASHER | 1 | |
| 20 | 108-2599 | SPACER | 1 | |
| 21 | 108-1606 | PIN - pulley tensioner | 1 | |
| 22 | 108-2600 | WASHER - pulley tensioner | 1 | |
| 23 | 55-7004 | SCREW - pulley | 1 | |
| 24 | 108-2601 | BELT | 1 |
