Установкa Thermo King TDD GO TRANSIT схема INLET/OUTLET MODULE – 265G7
Обновление от: 5/20/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 93-923 | BRACKET - tube | 1 | |
| 55-7035 | SCREW - bracket | 2 | ||
| 55-7170 | LOCKWASHER | 2 | ||
| 51-167 | FLATWASHER | 2 | ||
| 55-9837 | NUT - captive | 2 | ||
| 2 | 93-924 | BRACKET - clamp | 1 | |
| 55-7372 | SCREW - bracket | 2 | ||
| 55-7170 | LOCKWASHER | 2 | ||
| 51-167 | FLATWASHER | 2 | ||
| 55-9837 | NUT - captive | 2 | ||
| 3 | 55-7537 | ADAPTER | 1 | |
| 4 | 55-5742 | LOCKWASHER | 1 | |
| 5 | 55-9231 | NUT - bulkhead | 1 | |
| 6 | 51-1859 | CAP | 1 | |
| 7 | 55-7381 | ADAPTER | 1 | |
| 8 | 55-5999 | LOCKWASHER | 1 | |
| 9 | 55-9422 | NUT - bulkhead | 1 | |
| 10 | 33-920 | O-RING | 1 | |
| 11 | 51-1860 | CAP | 1 | |
| 12 | 55-7064 | ADAPTER | 1 | |
| 13 | 55-6843 | LOCKWASHER | 1 | |
| 14 | 55-6811 | NUT - bulkhead | 1 | |
| 15 | 51-1856 | CAP | 1 | |
| 16 | 55-7013 | CLAMP - tube | 2 | |
| 55-8993 | SCREW - clamp | 2 | ||
| 55-7170 | LOCKWASHER | 2 | ||
| 51-167 | FLATWASHER | 2 | ||
| 55-7373 | NUT - captive | 2 | ||
| 17 | 91-7703 | NAMEPLATE - liquid in | 1 | |
| 18 | 91-7550 | NAMEPLATE - liquid out | 1 |
