Установкa Thermo King TDD GO TRANSIT схема FRAME - BASE – 265G2
Обновление от: 5/15/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 98-9230 | CHANNEL - weldment | 1 | |
| 2 | 98-9231 | PLATE - base | 1 | |
| 55-9837 | NUT - captive | 14 | ||
| 55-6987 | SCREW - plate | 2 | ||
| 55-7066 | LOCKWASHER | 2 | ||
| 51-953 | FLATWASHER | 2 | ||
| 55-7035 | SCREW - plate | 1 | ||
| 55-7170 | LOCKWASHER | 1 | ||
| 51-167 | FLATWASHER | 1 | ||
| 3 | 98-9232 | SUPPORT - base | 3 | |
| 55-6998 | SCREW - support | 6 | ||
| 51-958 | FLATWASHER | 12 | ||
| 55-7344 | LOCKNUT | 10 | ||
| 55-6998 | SCREW - support | 4 | ||
| 51-958 | FLATWASHER | 8 | ||
| 4 | 98-9233 | GUIDE - channel | 2 | |
| 55-7035 | SCREW - guide | 8 | ||
| 55-7170 | LOCKWASHER | 8 | ||
| 51-167 | FLATWASHER | 8 | ||
| 55-9837 | NUT - captive | 8 |
