Установкa Thermo King TDD GO TRANSIT схема EVAPORATOR ASSEMBLY – 265G0
Обновление от: 5/15/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 67-2835 | COIL - evaporator | 1 | |
| 55-7373 | NUT - captive | 20 | ||
| 55-7035 | SCREW - evaporator | 7 | ||
| 55-7170 | LOCKWASHER | 7 | ||
| 51-167 | FLATWASHER | 7 | ||
| 55-6994 | SCREW - evaporator | 5 | ||
| 55-7170 | LOCKWASHER | 5 | ||
| 55-4414 | FLATWASHER | 5 | ||
| 2 | 93-932 | BRACKET | 3 | |
| 55-6994 | SCREW - bracket | 6 | ||
| 55-7170 | LOCKWASHER | 6 | ||
| 51-167 | FLATWASHER | 6 | ||
| 3 | 93-920 | BRACKET | 1 | |
| 55-7035 | SCREW - bracket | 1 | ||
| 55-7170 | LOCKWASHER | 1 | ||
| 51-167 | FLATWASHER | 1 | ||
| 4 | 99-3281 | MOUNT - bandwrap | 3 | |
| 55-5130 | RIVET - mount | 3 |
