Установкa Thermo King TD-II & TD-II MAX w/TK 3.95 Engine схема CONNECTORS – 117E4
Обновление от: 11/27/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 44-6292 | CONNECTOR - shroud (1-pin) | A/R | |
| 2 | 44-6381 | CONNECTOR - tower (1-pin) | A/R | |
| 3 | 44-5620 | CONNECTOR - shroud (2-pin) | A/R | |
| 4 | 44-5219 | CONNECTOR - tower (2-pin) | A/R | |
| 5 | 44-8938 | CONNECTOR - shroud (3-pin) | A/R | |
| 6 | 44-6248 | CONNECTOR - tower (3-pin) | A/R | |
| 7 | 44-5827 | CONNECTOR - shroud (4-pin) | A/R | |
| 8 | 44-5814 | CONNECTOR - tower (4-pin) | A/R | |
| 9 | 44-5600 | CONNECTOR - shroud (6-pin) | A/R | |
| 10 | 44-5622 | CONNECTOR - tower (6-pin) | A/R | |
| 11 | 44-4925 | CONNECTOR - shroud (6-pin) | A/R | |
| 12 | 44-5030 | CONNECTOR - tower (6-pin) | A/R | |
| 13 | 44-5718 | CONNECTOR - shroud (8-pin) | A/R | |
| 14 | 44-5719 | CONNECTOR - tower (8-pin) | A/R | |
| 15 | 41-6557 | TERMINAL - fingrip (12-14 ga) | A/R | |
| 55-7702 | TERMINAL - fingrip (16-18 ga) | A/R | ||
| 44-5066 | TERMINAL - fingrip (18-14 ga) | A/R | ||
| 44-5631 | TERMINAL - fingrip (18-20 ga) | A/R | ||
| 16 | 44-6453 | TERMINAL - fingrip (18 ga) | A/R | |
| 44-8092 | TERMINAL - fingrip (18-20 ga) | A/R | ||
| 44-8787 | TERMINAL - fingrip (14-16 ga) | A/R | ||
| 44-5629 | TERMINAL - fingrip (10-14 ga) | A/R | ||
| 41-9728 | TERMINAL - fingrip (12 ga) | A/R |
