Установкa Thermo King TA-1100 & A-1050N схема CONTROL BOX DOOR (TA-1100) – 192G4
Обновление от: 12/15/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 98-6460 | DOOR - control box | 1 | |
| 2 | 92-2443 | LATCH - door | 1 | |
| 3 | 45-2011 | CONTROLLER (uP AI) | 1 | |
| 40-787 | SOFTWARE (uP AI) | 1 | ||
| 55-7366 | SCREW - controller | 4 | ||
| 55-7370 | LOCKWASHER (internal tooth) | 4 | ||
| 55-7367 | NUT | 4 | ||
| 4 | 41-5981 | BOARD - pc interface | 1 | |
| 55-7696 | SCREW - board | 4 | ||
| 55-7031 | LOCKWASHER (internal tooth) | 4 | ||
| 55-7698 | NUT | 4 | ||
| 5 | 55-9865 | SPACER | 4 | |
| 6 | 99-3281 | MOUNT - cable tie | 8 | |
| 55-2260 | RIVET - mount | 8 | ||
| 7 | 92-3812 | RAIL - DIN | 1 | |
| 55-7368 | FLATWASHER | 2 | ||
| 55-2260 | RIVET - rail | 2 | ||
| 8 | 41-3892 | TERMINAL (gray) | 10 | |
| 9 | 41-3895 | ELEMENT - end | 2 | |
| 10 | 41-3894 | PLATE - end | 2 | |
| 11 | 92-3733 | CLAMP | 1 | |
| 12 | 45-2247 | DATALOGGER - DAS IV (optional) | 1 |
