Установкa Thermo King T14-M97 схема CONDENSER FAN GROUP – 251A9
Обновление от: 3/21/11
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 78-1775 | FAN - condenser motor assembly | 1 | |
| 2 | 77-3028 | ORIFICE - fan | 1 | |
| 3 | 77-3029 | GUARD - fan | 1 | |
| 4 | 78-1776 | MOTOR & FAN | 1 | |
| 5 | 55-2969 | SCREW - mounting | 4 | |
| 55-2959 | LOCKWASHER | 4 | ||
| 55-2904 | WASHER - special | 4 |
