Установкa Thermo King T14-M112 схема FRESH AIR DAMPER (800772) – 260F5
Обновление от: 11/30/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 93-117 | BOX - fresh air | 1 | |
| 203-412 | SEALER - polyurethane | A/R | ||
| 2 | 93-118 | PANEL - access | 1 | |
| 55-3098 | SCREW - panel | 4 | ||
| 55-1800 | LOCKWASHER | 4 | ||
| 55-8711 | INSERT | 4 | ||
| 3 | 93-599 | DOOR - fresh air | 1 | |
| 55-3098 | SCREW - door hinge | 2 | ||
| 55-8711 | INSERT | 2 | ||
| 4 | 55-3019 | SCREW - door arm | 1 | |
| 51-2292 | SPACER | 1 | ||
| 55-2965 | NUT | 1 | ||
| 55-4560 | NUT - locking | 1 | ||
| 5 | 93-120 | ARM - servomotor | 1 | |
| 6 | 41-3255 | SERVOMOTOR | 1 | |
| 55-2201 | FLATWASHER | 3 | ||
| 55-4223 | NUT | 3 |
