Установкa Thermo King T11-M172 схема CONDENSER AUXILIARY (703327) – 264G0
Обновление от: 1/24/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 93-666 | FRAME - condenser | 1 | |
| 2 | 51-2369 | BUSHING | 3 | |
| 3 | 92-8400 | MOUNT - bandwrap | 3 | |
| 55-2332 | BANDWRAP (.75 dia, black) | A/R | ||
| 4 | 33-5073 | INSULATION | 1 | |
| 5 | 33-5074 | INSULATION | 1 | |
| 6 | 33-5075 | INSULATION | 2 | |
| 7 | 98-5425 | GUARD - fan | 2 | |
| 55-2979 | SCREW fan | 8 | ||
| 55-1800 | LOCKWASHER | 8 | ||
| 55-2086 | FLATWASHER | 8 | ||
| 55-4727 | WASHER - special | 8 | ||
| 55-8711 | INSERT | 8 | ||
| 8 | 78-1460 | FAN - condenser | 2 | |
| 9 | 92-4932 | EDGE - protector | 2 | |
| 10 | 42-923 | HARNESS - condenser fans | 1 | |
| 11 | 33-3927 | GROMMET | 1 | |
| 12 | 42-924 | HARNESS - condenser fans, extension | 1 | |
| 13 | 67-2722 | COIL - condenser. microchannel | 1 | |
| 55-2957 | SCREW - coil (.875 in lg) | 3 | ||
| 55-3675 | SCREW - coil (1.75 in lg) | 3 | ||
| 51-2370 | BUSHING - spacer | 3 | ||
| 55-4414 | WASHER - special | 3 | ||
| 55-1800 | LOCKWASHER | 6 | ||
| 55-2086 | FLATWASHER | 3 | ||
| 55-8711 | INSERT | 6 | ||
| 14 | 93-667 | BRACKET - frame | 6 | |
| 55-2977 | SCREW - bracket (1.0 in lg) | 2 | ||
| 55-2957 | SCREW - bracket (.875 in lg) | 8 | ||
| 55-2086 | FLATWASHER | 10 | ||
| 55-1800 | LOCKWASHER | 2 | ||
| 55-8711 | INSERT | 2 |
