Установкa Thermo King T11-M132 & M134 (EL Dorado Honolulu) схема COMPRESSOR/ALTERNATOR MOUNTING – 226G2
Обновление от: 8/20/09
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 66-9493 | HOSE (#20, 34.5 in lg ss) | 1 | |
| 2 | 66-9465 | HOSE (#16, 33.2 in lg ss) | 2 | |
| 3 | 66-1273 | VALVE - check | 8 | |
| 4 | 66-9948 | HOSE (#20, 32.0 in) | 2 | |
| 5 | 55-7380 | ADAPTER - bhd (#16, ors) | 2 | |
| 6 | 55-7832 | ADAPTER - bhd (#20, ors) | 2 | |
| 7 | 61-279 | VALVE - suction (see 156G4) | 1 | |
| 8 | 61-277 | VALVE - discharge (see 226F8) | 1 | |
| 9 | 55-466 | ELBOW (1/4 fl x 1/4 mpt) | 1 | |
| 10 | 66-7180 | FITTING - suction | 1 | |
| 66-7183 | CAP (blue) | 1 | ||
| 11 | 66-8086 | FITTING - discharge | 1 | |
| 66-7182 | CAP (red) | 1 | ||
| 12 | 55-2330 | BANDWRAP (1.75 dia) | 10 |
