Установкa Thermo King T11-M132 & M134 (EL Dorado Honolulu) схема RECEIVER TANK GROUP – 213B8
Обновление от: 11/22/10
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 67-1191 | TANK - receiver | 1 | |
| 2 | 33-2419 | O-RING - sight glass | 1 | |
| 3 | 66-9918 | INDICATOR - liquid | 1 | |
| 4 | 61-1668 | TUBE - receiver outlet | 1 | |
| 5 | 61-1669 | TUBE - receiver inlet | 1 | |
| 6 | 92-5674 | BRACKET - receiver tank (top) | 1 | |
| 7 | 99-3060 | FITTING - saddle | 1 | |
| 8 | 66-7392 | VALVE - relief (see 119B8) | 1 | |
|
10-66-7392 | Предохранительный клапан | 3 480 ₽ |
|
| PP-66-7392 | Предохранительный клапан | 1 730 ₽ |
|
|
| 33-1015 | O-RING - relief valve | 1 | ||
| 33-1015 OEM | О-ринг фильтра-осушителя, 3/8" | 240 ₽ |
|
|
| 9 | 92-2309 | BRACKET - receiver tank | 1 | |
| 55-2977 | SCREW - bracket | 4 | ||
| 55-1800 | LOCKWASHER | 4 | ||
| 55-2086 | FLATWASHER | 4 | ||
| 55-8979 | INSERT | 4 | ||
| 55-6526 | INSERT - bottom bracket | 1 | ||
| 10 | 55-4955 | NUT - tank | 2 | |
| 55-2641 | FLATWASHER | 2 | ||
| 11 | 55-758 | CLAMP - tube | 1 | |
| 55-3095 | SCREW - clamp | 1 | ||
| 55-2086 | FLATWASHER | 2 | ||
| 55-1800 | LOCKWASHER | 1 | ||
| 55-1801 | NUT | 1 | ||
| 99-6872 | SPACER - clamp | 1 | ||
| 12 | 51-176 | CLAMP (0.250 dia) | 1 | |
| 55-1587 | SCREW - clamp | 1 | ||
| 13 | 92-8021 | CLAMP - tube | 2 | |
| 91-6158 | PLATE - clamp | 1 | ||
| 55-4811 | SCREW - clamp | 2 | ||
| 55-4953 | LOCKNUT | 2 |
