Установкa Thermo King T10-M8 Series схема COMPRESSOR GROUP (9180C29G07, KIT 714906) – 139F10
Обновление от: 9/17/10
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 102-910 | COMPRESSOR - X426 C5 (subassy, see 231C1) | 1 | |
| 2 | 33-2805 | GASKET - manifold & discharge valve | 1 | |
|
33-2805 OEM | Прокладка коллектора армированная, X426/430 | 800 ₽ |
|
|
10-33-2805 | Прокладка коллектора армированная, X426/430 | 620 ₽ |
|
|
10-33-2546 | Прокладка коллектора, X426/430 | 340 ₽ |
|
|
PP-33-2805 | Прокладка коллектора, X426/430 | 50 ₽ |
|
| 3 | 66-7038 | TUBE & VALVE - discharge (see 139F13) | 1 | |
| 4 | 55-6776 | SCREW - discharge valve | 2 | |
| 55-6804 | WASHER - sealing | 2 | ||
| 5 | 33-594 | O-RING | 1 | |
| 6 | 66-7039 | TUBE & VALVE - suction (see 139F14) | 1 | |
| 7 | 55-201 | SCREW - suction valve | 2 | |
| 55-895 | FLATWASHER | 2 | ||
| 8 | 33-544 | O-RING | 1 | |
| 9 | 33-2541 | GASKET - suction valve | 1 | |
| 10 | 55-9024 | KEY | 1 | |
|
10-55-9024 | Шпонка коленвала, X418/426/430 | 590 ₽ |
|
| 11 | 41-1501 | SWITCH - hpco (350 psi, for connectors see 115D14) | 1 | |
| 41-1502 | SWITCH - only | 1 | ||
| 12 | 44-7893 | SWITCH - lpco (for connectors see 115D14) | 1 | |
| 44-6263 | SWITCH - only | 1 | ||
| 13 | 55-308 | ELBOW | 1 | |
| 33-768 | GASKET - coupling | 1 | ||
| 14 | 41-2179 | HARNESS - compressor (for connectors see 115D14) | 1 | |
| 55-3024 | SCREW - ground | 1 | ||
| 55-2996 | LOCKWASHER | 1 | ||
| 15 | 55-5261 | CLAMP - harness | 3 | |
| 16 | 41-3345 | SENSOR - high temperature (for connectors see 115D14) | 1 | |
| 41-5394 | SENSOR - only | 1 | ||
| 17 | 41-1236 | HARNESS - compressor | 1 | |
| 18 | 204-972 | TOOL - keyway alignment | 1 | |
| 19 | 107-150 | KIT - clutch drive repair (see 153E7) | 1 | |
| 20 | 45-271 | FIELD - clutch (24VDC) | 1 |
