Установкa Thermo King T1 Series M52 Thru M67 схема MOTORS & FANS (RELIANCE MOTORS) – 142G8
Обновление от: 12/24/09
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 78-1116 | FAN - motor | 2 | |
| 77-1457 | HUB - fan | 1 | ||
| 55-3089 | SCREW - fan to shaft | 2 | ||
| 55-2959 | LOCKWASHER | 2 | ||
| 55-2958 | FLATWASHER | 2 | ||
| 2 | 104-740 | MOTOR - condenser fan | 2 | |
| 55-6141 | CONNECTOR (liquid tite) | 2 | ||
| 55-2635 | NUT - connector | 2 | ||
| 3 | 98-4550 | BRACKET - motor | 1 | |
| 55-2683 | SCREW - bracket | 6 | ||
| 55-5721 | SCREW (button head) | 2 | ||
| 55-2641 | FLATWASHER | 12 | ||
| 55-4931 | WASHER - special | 4 | ||
| 55-4955 | NUT | 8 | ||
| 4 | 99-7865 | NUTSTRIP - motor | 4 | |
| 55-3035 | RIVET - strip | 8 | ||
| 55-2969 | SCREW - motor | 8 | ||
| 55-4727 | WASHER - special | 8 | ||
| 55-2959 | LOCKWASHER | 8 | ||
| 5 | 104-741 | MOTOR - evaporator (see 153G9, for connectors see 115D14) | 1 | |
| 55-6141 | CONNECTOR (liquid tite) | 1 | ||
| 55-2635 | NUT - connector | 1 | ||
| 55-2969 | SCREW - motor | 4 | ||
| 55-2959 | LOCKWASHER | 4 | ||
| 55-4727 | FLATWASHER | 4 | ||
| 55-6713 | INSERT | 4 | ||
| 6 | 99-7780 | SPACER - motor mount | 2 | |
| 7 | 99-6871 | NUTSTRIP - motor | 2 | |
| 55-3035 | RIVET - strip | 4 | ||
| 8 | 77-2589 | COUPLING - flexible | 2 | |
| 9 | 77-2669 | SHAFT - blower | 2 | |
| 10 | 77-2664 | BEARING - flange | 2 | |
| 55-2961 | SCREW - bearing | 4 | ||
| 55-2641 | FLATWASHER | 4 | ||
| 55-4931 | WASHER - special | 4 | ||
| 55-4955 | NUT | 4 | ||
| 11 | 91-4664 | PLATE - bearing | 2 | |
| 55-1587 | SCREW - plate | 8 | ||
| 55-2086 | FLATWASHER | 8 | ||
| 55-1800 | LOCKWASHER | 8 | ||
| 55-7422 | INSERT | 8 | ||
| 12 | 91-4243 | CHANNEL - standoff (bearing plate) | 4 | |
| 55-1587 | SCREW - channel | 8 | ||
| 55-2086 | FLATWASHER | 16 | ||
| 55-4953 | NUT | 8 | ||
| 13 | 77-2517 | WHEEL - blower (ccw, roadside) | 1 | |
| 14 | 77-2516 | WHEEL - blower (cw, curbside) | 1 | |
| 15 | 98-4556 | CHANNEL - motor mount | 1 | |
| 55-2969 | SCREW - channel | 4 | ||
| 55-2959 | LOCKWASHER | 4 | ||
| 55-2958 | FLATWASHER | 8 | ||
| 55-6713 | INSERT | 4 | ||
| 16 | 41-3590 | CONTROLLER - motor | 2 | |
| 55-3000 | SCREW - controller | 8 | ||
| 55-2001 | FLATWASHER | 8 | ||
| 55-2964 | LOCKWASHER | 8 | ||
| 55-6554 | INSERT | 8 | ||
| 17 | 91-8048 | PLATE - controller | 1 | |
| 55-2977 | SCREW - plate | 4 | ||
| 55-2086 | FLATWASHER | 4 | ||
| 55-1800 | LOCKWASHER | 4 | ||
| 18 | 92-2117 | BRACKET - blockoff, motor (after 11/01) | 2 |
