Установкa Thermo King T1-M27 схема HAND HOLE COVER w/o UNLOADER – 105A4
Обновление от: 1/14/10
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 303-697 | GASKET - handhole cover | 1 | |
| 2 | 302-245 | COVER - handhole | 1 | |
| 3 | 55-270 | PLUG - pipe (hex head) | 2 | |
| 4 | 55-433 | PLUG - pipe (socket head) | 4 | |
| 5 | 55-402 | FLATWASHER (13/32) | 4 | |
| 6 | 306-578 | VALVE - oil drain (90) | 1 | |
| 7 | 55-1983 | CAP - sealing | 1 | |
| 8 | 55-2980 | SCREW (3/8-16 x 4, hh) | 16 | |
| 9 | 302-173 | STRAINER - oil | 1 | |
| 10 | 305-113 | ADAPTER (1/2 od x 3/8) | 1 | |
| 11 | 23-132 | HOUSING - compressor | 1 | |
| 12 | 55-7161 | PLUG - pipe (3/4) | 2 | |
| 13 | 306-250 | SIGHT GLASS | 2 | |
| 14 | 303-265 | O-RING - sight glass | 2 | |
| 15 | 55-538 | SCREW (1/4-20 x 5/8, hh) | 6 | |
| 16 | 302-164 | STRAINER - suction gas | 1 | |
| 17 | 303-700 | GASKET - suction service valve | 1 | |
| 18 | 33-2805 | GASKET - discharge service valve | 1 | |
|
33-2805 OEM | Прокладка коллектора армированная, X426/430 | 800 ₽ |
|
|
10-33-2805 | Прокладка коллектора армированная, X426/430 | 620 ₽ |
|
|
10-33-2546 | Прокладка коллектора, X426/430 | 340 ₽ |
|
|
PP-33-2805 | Прокладка коллектора, X426/430 | 50 ₽ |
|
| 303-703 | KIT - compressor gasket & o-ring | 1 |
