Установкa Thermo King T-DAIRY EMEIA схема NOISE ABATEMENT GROUP – 261F9
Обновление от: 2/4/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 33-5043 | QUILT - engine bay (door side) | 1 | |
| 2 | 33-5044 | QUILT - engine bay (front) | 1 | |
| 3 | 33-5045 | QUILT - engine bay | 1 | |
| 4 | 33-5046 | QUILT - engine bay (air intake) | 1 | |
| 5 | 33-5047 | QUILT - belly band | 1 | |
| 6 | 93-400 | COVER - engine | 1 | |
| 51-1964 | SCREW - cover | 2 | ||
| 7 | 33-5048 | QUILT - engine cover | 1 | |
| 8 | 93-401 | HINGE - frame (w/ pin) | 2 | |
| 55-9761 | SCREW - hinge | 2 | ||
| 9 | 98-9136 | SCREEN - top | 1 | |
| 10 | 92-7752 | HINGE - screen | 2 | |
| 11 | 55-9761 | SCREW - screen | 2 | |
| 55-8782 | WASHER - special | 2 | ||
| 12 | 93-401 | HINGE - frame (w/ pin) | 1 | |
| 13 | 93-402 | HINGE - frame (w/ pin, control box end) | 1 | |
| 55-9761 | SCREW - hinge | 2 | ||
| 14 | 98-8951 | CAP - top | 1 |
