Установкa Thermo King T-DAIRY EMEIA схема CONDENSER COVERS & GRILLES – 259F5
Обновление от: 12/12/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 98-8921 | CAP - top | 1 | |
| 51-2123 | INSERT - threaded (M6) | 13 | ||
| 51-1964 | SCREW - cap | 13 | ||
| 2 | 98-8927 | GRILLE - upper | 1 | |
| 51-2187 | SCREW - grille | 8 | ||
| 3 | 92-9698 | NAMPLATE - TK logo | 1 | |
| 4 | 98-8920 | PANEL - condenser (bottom) | 1 | |
| 55-9761 | SCREW - panel (M6 X 25) | 5 | ||
| 51-1964 | SCREW - panel special) | 4 | ||
| 5 | 98-8928 | GRILLE - lower | 1 | |
| 51-2187 | SCREW - grille | 2 | ||
| 6 | 92-7552 | CAP - hose management | 2 | |
| 7 | 92-9580 | BRACKET - band | 1 | |
| 55-7035 | SCREW - bracket to band | 3 | ||
| 55-7075 | FLATWASHER | 3 | ||
| 55-6996 | LOCKWASHER | 3 | ||
| 8 | 92-9609 | BRACKET - top cap (left, roadside) | 1 | |
| 55-9761 | SCREW - bracket to cap | 2 | ||
| 9 | 98-8926 | BRACKET - top cap (right, curbside) | 1 | |
| 33-1215 | GROMMET | 1 | ||
| 55-9761 | SCREW - bracket to cap | 2 |
