Установкa Thermo King T-680S TSA схема DAS CONTROL BOX – 235H9
Обновление от: 12/15/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 40-1125 | KIT - DAS (EMEIA, 1 zone, incl sensor and 20 ft harness) | 1 | |
| 2 | 45-2247 | DATALOGGER - DAS IV | 1 | |
| 203-439 | BATTERY | 1 | ||
| 3 | 91-9305 | NAMEPLATE - DAS Sensor Grade | 1 | |
| 4 | 41-8743 | HARNESS - DAS communications | 1 | |
| 5 | 44-9904 | RECEPTACLE - 12-pin | 1 | |
| 44-9905 | WEDGE - 12-pin | 1 | ||
| 44-9591 | PIN - terminal (18 ga) | 18 | ||
| 44-9894 | PIN - sealing | 3 | ||
| 6 | 41-5367 | BOX ASSEMBLY - DAS | 1 | |
| 7 | 91-9585 | BOX - DAS | 1 | |
| 8 | 41-2405 | CONNECTOR - receptacle (5-pin) | 1 | |
| 9 | 44-8329 | RECEPTACLE (6-pin) | 1 | |
| 10 | 55-3427 | SCREW - receptacle | 8 | |
| 55-2359 | FLATWASHER | 16 | ||
| 11 | 55-2361 | NUT | 8 | |
| 12 | 55-6742 | CONNECTOR - harness grip | 1 | |
| 13 | 55-2635 | NUT | 1 | |
| 14 | 91-9586 | COVER - box | 1 | |
| 15 | 55-3025 | SCREW - cover | 4 | |
| 16 | 55-2001 | FLATWASHER | 4 | |
| 17 | 99-3685 | CHAIN | 2 | |
| 18 | 41-2406 | CAP - dust | 1 | |
| 19 | 44-8333 | CAP - dust | 1 | |
| 20 | 55-2332 | BANDWRAP | 2 | |
| 21 | 41-8703 | HARNESS - DAS | 1 | |
| 22 | 41-7585 | PLUG - 12-pin (to DAS remote box) | 1 | |
| 41-7586 | WEDGE - 12-pin | 1 | ||
| 23 | 41-8736 | PLUG - 4-pin (J DAS IN) | 1 | |
| 41-8815 | WEDGE - 4-pin | 1 | ||
| 24 | 41-8733 | PLUG - 2-pin (J DAS OUT) | 1 | |
| 41-8820 | WEDGE - 2-pin | 1 | ||
| 44-9587 | SOCKET 18GA | 6 | ||
| 25 | 44-2789 | TERMINAL - ring (ground) | 1 | |
| 26 | 41-5709 | PLUG - 8-pin (comm harness) | 1 | |
| 33-3908 | GASKET - 8-pin plug | 1 | ||
| 41-2457 | SOCKET (18 ga) | 8 | ||
| 41-6256 | SEAL - wire | 5 | ||
| 27 | 41-3359 | PLUG - 35-pin (DAS) | 1 | |
| 41-2457 | SOCKET - terminal (18 ga) | 29 | ||
| 28 | 41-8834 | RECEPTACLE - 12-pin (sensor harness) | 1 | |
| 41-8835 | WEDGE - 12-pin | 1 | ||
| 44-9591 | PIN - terminal (18 ga) | 12 | ||
| 29 | 40-1132 | KIT - DAS SENSOR (2 zone & 3 zone, 10 ft & 40 ft sensor harnesses, does not include DAS module) | A/R | |
| 41-2985 | HARNESS - sensor (10 ft) | 1 | ||
| 41-2986 | HARNESS - sensor (40 ft) | 2 | ||
| 30 | 41-9657 | SENSOR (graded) | A/R |
