Установкa Thermo King T-680S TSA схема DEHYDRATOR GROUP – 235H6
Обновление от: 12/12/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 61-800 | DEHYDRATOR (inc o-rings) | 1 | |
|
10-61-800 | Дегидратор, KD-II/MD-II/MD-XXX/RD-II/TD-II / T/TS-Series | 4 650 ₽ |
|
|
PP-61-800 | Дегидратор, KD-II/MD-II/MD-XXX/RD-II/TD-II / T/TS-Series | 1 600 ₽ |
|
| 2 | 33-1015 | O-RING | 2 | |
| 33-1015 OEM | О-ринг фильтра-осушителя, 3/8" | 240 ₽ |
|
|
| 3 | 55-8268 | SHOULDER | 2 | |
| 4 | 55-8267 | NUT - shoulder | 2 | |
| 5 | 33-4984 | PAD - dehydrator | 1 | |
| 6 | 92-7545 | CLAMP - dehydrator | 1 | |
| 55-7035 | SCREW - clamp | 2 | ||
| 55-7075 | FLATWASHER | 2 | ||
| 55-7170 | LOCKWASHER | 2 | ||
| 55-9084 | INSERT - threaded | 2 |
