Установкa Thermo King T-1200R SPECTRUM EMEIA схема ENGINE COOLING SYSTEM T-1000/1200 – 236B2
Обновление от: 4/14/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 67-2433 | COIL - condenser/radiator | 1 | |
| 51-1841 | SCREW - coil | 12 | ||
| 55-7727 | LOCKWASHER | 12 | ||
| 55-7144 | WASHER - special | 12 | ||
| 2 | 13-1016 | HOSE - engine to radiator (upper, EPDM) | 1 | |
| 13-1012 | HOSE - engine to radiator (upper, silicone) | 1 | ||
| 3 | 55-2818 | CLAMP - hose (EPDM) | 4 | |
| 55-3401 | CLAMP - hose (silicone) | 4 | ||
| 4 | 13-1018 | HOSE - engine to radiator (lower, EPDM) | 1 | |
| 13-1014 | HOSE - engine to radiator (lower, silicone) | 1 | ||
| 5 | 13-1087 | PUMP - water (see 185F9) | 1 | |
| 6 | 13-1017 | HOSE - coil to coolant tank (EPDM) | 1 | |
| 13-1013 | HOSE - coil to coolant tank (silicone) | 1 | ||
| 7 | 55-5002 | CLAMP - hose | 2 | |
| 8 | 10-433 | KIT - coolant tank (includes items 9 - 11, 22 - 24) | 1 | |
| 13-1057 | TANK - coolant (replaces 13-984) | 1 | ||
|
10-13-1057 | Расширительный бачок, T-Series | 17 820 ₽ |
|
| 9 | 42-427 | SWITCH - coolant level | 1 | |
| 33-3007 | O-RING - switch | 1 | ||
| 33-3007 OEM | О-ринг сервисного клапана, X426/430/640 | 130 ₽ |
|
|
| 10 | 13-990 | CAP - tank (15 psi) | 1 | |
|
10-13-990 | Крышка расширительного бачка, T-Series | 1 490 ₽ |
|
| 11 | 13-957 | CAP - overflow | 1 | |
| 55-5955 | SCREW - tank | 4 | ||
| 55-7478 | LOCKWASHER | 4 | ||
| 55-4638 | FLATWASHER | 4 | ||
| 12 | 98-8282 | HOSE - overflow | A/R | |
| 13 | 92-7627 | COVER - tank | 1 | |
| 51-718 | SCREW - cover | 4 | ||
| 14 | 13-1011 | TUBE - coolant drain | 1 | |
| 15 | 55-7134 | COCK - drain | 1 | |
| 66-2672 | ADAPTER - drain cock | 1 | ||
| 203-385 | SEALER - thread | A/R | ||
| 16 | 55-6388 | CLAMP - tube | 3 | |
| 55-8464 | SCREW - clamp (M6X35) | 2 | ||
| 55-7029 | SCREW - clamp (M6X65) | 1 | ||
| 55-5929 | SPACER | 1 | ||
| 55-7170 | LOCKWASHER | 3 | ||
| 55-7075 | FLATWASHER | 3 | ||
| 17 | 92-7531 | BRACKET - connector | 1 | |
| 44-9906 | TAB - connector | 2 | ||
| 55-3065 | CLAMP - harness (1/2 in) | 1 | ||
| 55-731 | SCREW - clamp | 2 | ||
| 55-411 | FLATWASHER | 2 | ||
| 55-4118 | NUT | 2 | ||
| 18 | 41-6538 | SENSOR - engine coolant | 1 | |
|
10-41-6538 | Сенсор температуры двигателя, SLX/SB-XXX | 18 500 ₽ |
|
|
PP-41-6538 | Сенсор температуры двигателя, SLX/SB-XXX | 3 210 ₽ |
|
| 19 | 55-6789 | COCK - drain | 1 | |
| 20 | 11-8041 | HOSE - bleed (3/8 id EPDM, use w/ tank 13-984) | A/R | |
| 12-538 | HOSE - bleed (3/8 id silicone, use w/ tank 13-984) | 1 | ||
| 21 | 51-1810 | FITTING - hose (3/8 thread, 3/8 barb) | 1 | |
| 22 | 13-1054 | HOSE - bleed (5/8 id EPDM, use w/ tank 13-1057) | 1 | |
| 13-1055 | HOSE - bleed (5/8 id silicone, use w/ tank 13-1057) | 1 | ||
| 23 | 55-4167 | FITTING - hose (3/8 thread, 5/8 barb) | 1 | |
| 24 | 55-4552 | CLAMP - hose | 1 | |
| 55-4606 | SCREW - clamp | 1 | ||
| 55-4638 | FLATWASHER | 1 | ||
| 55-7478 | LOCKWASHER | 1 |
