Установкa Thermo King T-1000R SPECTRUM EMEIA схема REFRIGERATION - CONDENSER (T-1000R w/ micro-channel coil) – 259H8
Обновление от: 8/17/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 8102-911 | COMPRESSOR - X426 LS C5 (dry new exchange, see 242G9) | 1 | |
| 2 | 66-129 | VALVE - discharge (see 242G9) | 1 | |
|
10-66-129 | Сервисный вентиль, X426/430 | 22 340 ₽ |
|
| 3 | 61-4798 | TUBE - valve to strainer | 1 | |
| 4 | 61-4682 | STRAINER - discharge | 1 | |
| 5 | 61-6287 | TUBE - strainer to condenser valve | 1 | |
| 6 | 11-2886 | VALVE | 1 | |
| 7 | 61-4861 | VALVE - condenser inlet | 1 | |
| 8 | 61-5952 | TUBE - valve to condenser | 1 | |
| 9 | 67-2726 | COIL - condenser/radiator (see 259E8) | 1 | |
|
10-67-2966 | Конденсатор, T-1000/1200 | 68 440 ₽ |
|
| PP-67-2966 | Конденсатор, T-1000/1200 | 36 500 ₽ |
|
|
| 10 | 61-6068 | TUBE - condenser to check valve | 1 | |
| 11 | 66-5722 | VALVE - check | 1 | |
| 12 | 61-6135 | TUBE - check valve to receiver tank | 1 | |
| 13 | 67-2709 | TANK - receiver (see 235H5) | 1 | |
| 14 | 66-7392 | VALVE - relief | 1 | |
|
10-66-7392 | Предохранительный клапан | 3 480 ₽ |
|
| PP-66-7392 | Предохранительный клапан | 1 730 ₽ |
|
|
| 15 | 61-6136 | TUBE - tank to dehydrator | 1 | |
| 16 | 61-800 | DEHYDRATOR (see 235H6) | 1 | |
|
10-61-800 | Дегидратор, KD-II/MD-II/MD-XXX/RD-II/TD-II / T/TS-Series | 4 650 ₽ |
|
|
PP-61-800 | Дегидратор, KD-II/MD-II/MD-XXX/RD-II/TD-II / T/TS-Series | 1 600 ₽ |
|
| 17 | 61-5956 | TUBE - dehydrator to evaporator | 1 | |
| 18 | 61-6132 | TUBE - valve to receiver tank | 1 | |
| 19 | 61-5960 | TUBE - solenoid to coil | 1 | |
| 20 | 61-6131 | TUBE - valve to tube | 1 | |
| 21 | 61-6071 | TUBE - check valve to solenoid | 1 | |
| 22 | 66-6384 | VALVE - hot gas & purge (see 116G14) | 2 | |
| 10-66-6384 | Соленоид, MD/RD-II / SB-III/ SMX/SMX-II/V-Series | 13 550 ₽ |
|
|
| 23 | 61-6130 | TUBE - hot gas (valve to evaporator) | 1 | |
| 24 | 67-2424 | TANK - accumulator | 1 | |
| 25 | 55-3682 | ELBOW | 2 | |
| 26 | 61-4709 | TUBE - evaporator to elbow | 1 | |
| 66-3570 | FITTING - saddle | 1 | ||
| 27 | 11-5513 | VALVE - elbow | 1 | |
| 11-7777 | INSERT - valve | 1 | ||
| 55-1983 | CAP - valve | 1 | ||
| 28 | 61-4527 | VALVE - pressure regulator | 1 | |
| 14-60052-02 OEM | Клапан KVL Ø 28мм, Maxima / Supra 5XX/8XX/850MT/9XX/950MT/1150/1150MT/1250/1250MT | 39 280 ₽ |
|
|
|
10-61-4527 | Клапан KVL Ø 28мм, MD/KD-II/MD-II/TS/T-Series | 27 760 ₽ |
|
| P-14-00205-01 | Клапан KVL Ø 28мм, Maxima / Supra 5XX/8XX/850MT/9XX/950MT/1150/1150MT/1250/1250MT | 27 760 ₽ |
|
|
| 29 | 61-5678 | TUBE - suction (valve to joint) | 1 | |
| 30 | 61-4800 | TUBE - suction (joint to valve) | 1 | |
| 31 | 66-5492 | VALVE - suction (see 242G9) | 1 | |
| 32 | 61-5718 | TUBE - accumulator to check valve | 1 | |
| 33 | 61-5725 | VALVE - check | 1 |
